QUASAR 60

IN
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (TECH versions).
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type II light distribution.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
QUASAR 60 B

QUASAR 60 B

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
070406 LED 38 W 80 3000 Type II - 5107 3204 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070406
070407 LED 38 W 80 4000 Type II - 5472 3250 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070407
070408 LED 38 W 80 3000 Type II - 5107 3204 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070408
070409 LED 38 W 80 4000 Type II - 5472 3250 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070409
070410 LED 38 W 80 3000 Type II - 5107 3204 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070410
070411 LED 38 W 80 4000 Type II - 5472 3250 L80 B10 130000 Download

Documentation: QUASAR 60 B - 070411

Sources

LED 38 W
QUASAR 60 DOUBLE TECH

QUASAR 60 DOUBLE TECH

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
070424 LED 38 W 120/277 V 80 3000 Type II - 5107 4026 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070424
070425 LED 38 W 120/277 V 80 4000 Type II - 5472 4082 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070425
070426 LED 38 W 120/277 V 80 3000 Type II - 5107 4026 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070426
070427 LED 38 W 120/277 V 80 4000 Type II - 5472 4082 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070427
070428 LED 38 W 120/277 V 80 3000 Type II - 5107 4026 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070428
070429 LED 38 W 120/277 V 80 4000 Type II - 5472 4082 L80 B10 130000 Download

Documentation: QUASAR 60 DOUBLE TECH - 070429

Sources

LED 38 W
QUASAR 60 M

QUASAR 60 M

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
070394 LED 19 W 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070394
070395 LED 19 W 80 4000 Type II - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070395
070396 LED 19 W 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070396
070397 LED 19 W 80 4000 Type II - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070397
070398 LED 19 W 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070398
070399 LED 19 W 80 4000 Type II - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M - 070399

Sources

LED 19 W
QUASAR 60 M EMPK

QUASAR 60 M EMPK

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
070400 LED 19 W 120/277 V 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070400
070401 LED 19 W 120/277 V 80 4000 Type II - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070401
070402 LED 19 W 120/277 V 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070402
070403 LED 19 W 120/277 V 80 4000 - - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070403
070404 LED 19 W 120/277 V 80 3000 Type II - 2554 1631 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070404
070405 LED 19 W 120/277 V 80 4000 - - 2736 1655 L80 B10 130000 Download

Documentation: QUASAR 60 M EMPK - 070405

Sources

LED 19 W
QUASAR 60 TECH

QUASAR 60 TECH

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
070412 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070412
070413 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070413
070414 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070414
070415 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070415
070416 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070416
070417 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH - 070417

Sources

LED 19 W
QUASAR 60 TECH EMPK

QUASAR 60 TECH EMPK

Optic | Asymmetric Extra-Wide
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
070418 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070418
070419 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070419
070420 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070420
070421 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070421
070422 LED 19 W 120/277 V 80 3000 Type II - 2554 2050 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070422
070423 LED 19 W 120/277 V 80 4000 Type II - 2736 2078 L80 B10 130000 Download

Documentation: QUASAR 60 TECH EMPK - 070423

Sources

LED 19 W

Product Family

QUASAR 10 QUASAR 10
QUASAR 20 QUASAR 20
QUASAR 30 QUASAR 30
QUASAR 30 CEILING QUASAR 30 CEILING
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
