QUASAR 30 CEILING

IN
  • Ceiling mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Diffuse light emission (TECH).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Ceiling mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Diffuse light emission (TECH).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
070606 LED 21 W 120/277 V 80 3000 - - 2276 1756 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070606

070607 LED 21 W 120/277 V 80 3000 - - 2276 1756 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070607

070608 LED 21 W 120/277 V 80 3000 - - 2276 1756 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070608

070609 LED 21 W 120/277 V 80 4000 - - 2384 1889 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070609

070610 LED 21 W 120/277 V 80 4000 - - 2384 1889 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070610

070611 LED 21 W 120/277 V 80 4000 - - 2384 1889 L80 B10 100000 Download

Documentation: QUASAR 30 CEILING TECH - 070611

Sources

LED 21 W
