QUASAR 20

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
QUASAR 20 DOUBLE TECH

QUASAR 20 DOUBLE TECH

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070174 LED 22 W 120/277 V 80 3000 Type I - 2000 1211 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070174
070175 LED 22 W 120/277 V 80 4000 Type I - 2280 1332 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070175
070176 LED 22 W 120/277 V 80 3000 Type I - 2000 1211 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070176
070177 LED 22 W 120/277 V 80 4000 Type I - 2280 1332 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070177
070178 LED 22 W 120/277 V 80 3000 Type I - 2000 1211 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070178
070179 LED 22 W 120/277 V 80 4000 Type I - 2280 1332 L80 B10 60000 QUASAR 20 DOUBLE TECH Download

Documentation: QUASAR 20 DOUBLE TECH - 070179

Sources

LED 22 W
QUASAR 20 TECH

QUASAR 20 TECH

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - Single (TECH) or dual (DOUBLE TECH) light emission.
  • - Type I light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Junction box mounting plate included (for 4" octagon box only, provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070168 LED 11 W 120/277 V 80 3000 Type I - 1000 695 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070168
070169 LED 11 W 120/277 V 80 4000 Type I - 1140 764 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070169
070170 LED 11 W 120/277 V 80 3000 Type I - 1000 695 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070170
070171 LED 11 W 120/277 V 80 4000 Type I - 1140 764 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070171
070172 LED 11 W 120/277 V 80 3000 Type I - 1000 695 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070172
070173 LED 11 W 120/277 V 80 4000 Type I - 1140 764 L80 B10 60000 QUASAR 20 TECH Download

Documentation: QUASAR 20 TECH - 070173

Sources

LED 11 W
