FOCUS+ 3

IN
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - NEMA 3H x 3V light distribution (C/I).
  • - NEMA 4H x 4V light distribution (C/M).
  • - NEMA 5H x 5V light distribution (C/W).
  • - NEMA 3H x 7V light distribution (Type I).
  • - NEMA 5H x 7V light distribution (Type III).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
FOCUS+ 3 C/I

FOCUS+ 3 C/I

INTENSIVE CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 3V light distribution (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071870 LED 54 W 120-277 V 70 3000 - 17° 5040 3759 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/I - 071870
071882 LED 54 W 120-277 V 70 4000 - 17° 5640 4199 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/I - 071882

Sources

LED 54 W
FOCUS+ 3 C/M

FOCUS+ 3 C/M

MEDIUM CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 4V light distribution (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071872 LED 54 W 120-277 V 70 3000 - 34° 5040 3683 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/M - 071872
071884 LED 54 W 120-277 V 70 4000 - 34° 5640 4114 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/M - 071884

Sources

LED 54 W
FOCUS+ 3 C/W

FOCUS+ 3 C/W

WIDE CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 5V light distribution (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071874 LED 54 W 120-277 V 70 3000 - 56° 5040 3449 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/W - 071874
071886 LED 54 W 120-277 V 70 4000 - 56° 5640 3852 L70 B10 60000 Download

Documentation: FOCUS+ 3 C/W - 071886

Sources

LED 54 W
FOCUS+ 3 ELL

FOCUS+ 3 ELL

ELLIPTICAL REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071876 LED 54 W 120-277 V 70 3000 - 15°x40° 5040 3964 L70 B10 60000 Download

Documentation: FOCUS+ 3 ELL - 071876
071888 LED 54 W 120-277 V 70 4000 - 15°x40° 5640 4428 L70 B10 60000 Download

Documentation: FOCUS+ 3 ELL - 071888

Sources

LED 54 W
FOCUS+ 3 SA C/I

FOCUS+ 3 SA C/I

INTENSIVE CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 3V light distribution (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070508 LED 54 W 120-277 V 50/60 Hz 70 3000 - 17° 5040 3759 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/I - 070508
070509 LED 54 W 120-277 V 50/60 Hz 70 3000 - 17° 5040 3759 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/I - 070509
070520 LED 54 W 120-277 V 50/60 Hz 70 4000 - 17° 5640 4199 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/I - 070520
070521 LED 54 W 120-277 V 50/60 Hz 70 4000 - 17° 5640 4199 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/I - 070521

Sources

LED 54 W
FOCUS+ 3 SA C/M

FOCUS+ 3 SA C/M

MEDIUM CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 4V light distribution (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070510 LED 54 W 120-277 V 50/60 Hz 70 3000 - 34° 5040 3683 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/M - 070510
070511 LED 54 W 120-277 V 50/60 Hz 70 3000 - 34° 5040 3683 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/M - 070511
070522 LED 54 W 120-277 V 50/60 Hz 70 4000 - 34° 5640 4114 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/M - 070522
070523 LED 54 W 120-277 V 50/60 Hz 70 4000 - 34° 5640 4114 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/M - 070523

Sources

LED 54 W
FOCUS+ 3 SA C/W

FOCUS+ 3 SA C/W

WIDE CIRCLE REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 5V light distribution (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070512 LED 54 W 120-277 V 50/60 Hz 70 3000 - 56° 5040 3449 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/W - 070512
070513 LED 54 W 120-277 V 50/60 Hz 70 3000 - 56° 5040 3449 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/W - 070513
070524 LED 54 W 120-277 V 50/60 Hz 70 4000 - 56° 5640 3852 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/W - 070524
070525 LED 54 W 120-277 V 50/60 Hz 70 4000 - 56° 5640 3852 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA C/W - 070525

Sources

LED 54 W
FOCUS+ 3 SA ELL

FOCUS+ 3 SA ELL

ELLIPTICAL REFLECTOR
  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 4H x 3V light distribution (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070514 LED 54 W 120-277 V 50/60 Hz 70 3000 - 15°x40° 5040 3964 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA ELL - 070514
070515 LED 54 W 120-277 V 50/60 Hz 70 3000 - 15°x40° 5040 3964 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA ELL - 070515
070526 LED 54 W 120-277 V 50/60 Hz 70 4000 - 15°x40° 5640 4428 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA ELL - 070526
070527 LED 54 W 120-277 V 50/60 Hz 70 4000 - 15°x40° 5640 4428 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA ELL - 070527

Sources

LED 54 W
FOCUS+ 3 SA TYPE I

FOCUS+ 3 SA TYPE I

  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070516 LED 54 W 120-277 V 50/60 Hz 70 3000 Type I - 5040 3409 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE I - 070516
070517 LED 54 W 120-277 V 50/60 Hz 70 3000 Type I - 5040 3409 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE I - 070517
070528 LED 54 W 120-277 V 50/60 Hz 70 4000 Type I - 5640 3807 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE I - 070528
070529 LED 54 W 120-277 V 50/60 Hz 70 4000 Type I - 5640 3807 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE I - 070529

Sources

LED 54 W
FOCUS+ 3 SA TYPE III

FOCUS+ 3 SA TYPE III

  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 7V light distribution (Type III).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
070518 LED 54 W 120-277 V 50/60 Hz 70 3000 Type III - 5040 3420 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE III - 070518
070519 LED 54 W 120-277 V 50/60 Hz 70 3000 Type III - 5040 3420 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE III - 070519
070530 LED 54 W 120-277 V 50/60 Hz 70 4000 Type III - 5640 3820 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE III - 070530
070531 LED 54 W 120-277 V 50/60 Hz 70 4000 Type III - 5640 3820 L70 B10 60000 Download

Documentation: FOCUS+ 3 SA TYPE III - 070531

Sources

LED 54 W
FOCUS+ 3 TYPE I

FOCUS+ 3 TYPE I

  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071878 LED 54 W 120-277 V 70 3000 Type I - 5040 3409 L70 B10 60000 Download

Documentation: FOCUS+ 3 TYPE I - 071878
071890 LED 54 W 120-277 V 70 4000 Type I - 5640 3807 L70 B10 60000 Download

Documentation: FOCUS+ 3 TYPE I - 071890

Sources

LED 54 W
FOCUS+ 3 TYPE III

FOCUS+ 3 TYPE III

  • Long-lasting energy-efficient architectural, landscape and professional flood light series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing, ring/faceplate, and adjustable mounting bracket.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - NEMA 5H x 7V light distribution (Type III).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V - Dimmable 0-10 V
071880 LED 54 W 120-277 V 70 3000 Type III - 5040 3420 L70 B10 60000 Download

Documentation: FOCUS+ 3 TYPE III - 071880
071892 LED 54 W 120-277 V 70 4000 Type III - 5640 3820 L70 B10 60000 Download

Documentation: FOCUS+ 3 TYPE III - 071892

Sources

LED 54 W

Product Family

FOCUS+ 1 FOCUS+ 1
FOCUS+ 2 FOCUS+ 2
FOCUS+ ZERO FOCUS+ ZERO
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
