FOCUS+ 2

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Circular Wide optics (C/W).
  • - NEMA 3H x 7V light distribution (Type I).
  • - NEMA 5H x 7V light distribution (Type IV).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
FOCUS+ 2 C/I

FOCUS+ 2 C/I

Optic | Circular Intensive
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071845 LED 27 W 120/277 V 70 3000 - 17° 2520 1960 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/I - 071845
071850 LED 27 W 120/277 V 70 4000 - 17° 2820 2189 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/I - 071850

Sources

LED 27 W
FOCUS+ 2 C/M

FOCUS+ 2 C/M

Optic | Circular Medium
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071846 LED 27 W 120/277 V 70 3000 - 34° 2520 1953 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/M - 071846
071851 LED 27 W 120/277 V 70 4000 - 34° 2820 2181 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/M - 071851

Sources

LED 27 W
FOCUS+ 2 C/W

FOCUS+ 2 C/W

Optic | Circular Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071847 LED 27 W 120/277 V 70 3000 - 56° 2520 1824 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/W - 071847
071852 LED 27 W 120/277 V 70 4000 - 56° 2820 2037 L70 B10 60000 Download

Documentation: FOCUS+ 2 C/W - 071852

Sources

LED 27 W
FOCUS+ 2 ELL

FOCUS+ 2 ELL

Optic | Elliptical - ELL
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071848 LED 27 W 120/277 V 70 3000 - 15°x40° 2520 2052 L70 B10 60000 Download

Documentation: FOCUS+ 2 ELL - 071848
071853 LED 27 W 120/277 V 70 4000 - 15°x40° 2820 2292 L70 B10 60000 Download

Documentation: FOCUS+ 2 ELL - 071853

Sources

LED 27 W
FOCUS+ 2 SA C/I

FOCUS+ 2 SA C/I

Optic | Circular Intensive
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070484 LED 27 W 120/277 V 70 3000 - 17° 2520 1960 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/I - 070484
070485 LED 27 W 120/277 V 70 3000 - 17° 2520 1960 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/I - 070485
070496 LED 27 W 120/277 V 70 4000 - 17° 2820 2189 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/I - 070496
070497 LED 27 W 120/277 V 70 4000 - 17° 2820 2189 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/I - 070497

Sources

LED 27 W
FOCUS+ 2 SA C/M

FOCUS+ 2 SA C/M

Optic | Circular Medium
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Medium optics (C/M).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070486 LED 27 W 120/277 V 70 3000 - 34° 2520 1953 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/M - 070486
070487 LED 27 W 120/277 V 70 3000 - 34° 2520 1953 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/M - 070487
070498 LED 27 W 120/277 V 70 4000 - 34° 2820 2181 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/M - 070498
070499 LED 27 W 120/277 V 70 4000 - 34° 2820 2181 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/M - 070499

Sources

LED 27 W
FOCUS+ 2 SA C/W

FOCUS+ 2 SA C/W

Optic | Circular Wide
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Wide optics (C/W).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070488 LED 27 W 120/277 V 70 3000 - 56° 2520 1824 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/W - 070488
070489 LED 27 W 120/277 V 70 3000 - 56° 2520 1824 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/W - 070489
070500 LED 27 W 120/277 V 70 4000 - 56° 2820 2037 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/W - 070500
070501 LED 27 W 120/277 V 70 4000 - 56° 2820 2037 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA C/W - 070501

Sources

LED 27 W
FOCUS+ 2 SA ELL

FOCUS+ 2 SA ELL

Optic | Elliptical - ELL
  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Elliptical optics (ELL).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070490 LED 27 W 120/277 V 70 3000 - 15°x40° 2520 2052 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA ELL - 070490
070491 LED 27 W 120/277 V 70 3000 - 15°x40° 2520 2052 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA ELL - 070491
070502 LED 27 W 120/277 V 70 4000 - 15°x40° 2820 2292 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA ELL - 070502
070503 LED 27 W 120/277 V 70 4000 - 15°x40° 2820 2292 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA ELL - 070503

Sources

LED 27 W
FOCUS+ 2 SA TYPE I

FOCUS+ 2 SA TYPE I

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070492 LED 27 W 120/277 V 70 3000 Type I - 2520 1853 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE I - 070492
070493 LED 27 W 120/277 V 70 3000 Type I - 2520 1853 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE I - 070493
070504 LED 27 W 120/277 V 70 4000 Type I - 2820 2069 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE I - 070504
070505 LED 27 W 120/277 V 70 4000 Type I - 2820 2069 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE I - 070505

Sources

LED 27 W
FOCUS+ 2 SA TYPE IV

FOCUS+ 2 SA TYPE IV

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 7V light distribution (Type IV).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070494 LED 27 W 120/277 V 70 3000 Type IV - 2520 1857 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE IV - 070494
070495 LED 27 W 120/277 V 70 3000 Type IV - 2520 1857 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE IV - 070495
070506 LED 27 W 120/277 V 70 4000 Type IV - 2820 2074 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE IV - 070506
070507 LED 27 W 120/277 V 70 4000 Type IV - 2820 2074 L70 B10 60000 Download

Documentation: FOCUS+ 2 SA TYPE IV - 070507

Sources

LED 27 W
FOCUS+ 2 TYPE I

FOCUS+ 2 TYPE I

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 3H x 7V light distribution (Type I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071860 LED 27 W 120/277 V 70 4000 Type I - 2820 2069 L70 B10 60000 Download

Documentation: FOCUS+ 2 TYPE I - 071860
071924 LED 27 W 120/277 V 70 3000 Type I - 2520 1853 L70 B10 60000 Download

Documentation: FOCUS+ 2 TYPE I - 071924

Sources

LED 27 W
FOCUS+ 2 TYPE IV

FOCUS+ 2 TYPE IV

  • Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - NEMA 5H x 7V light distribution (Type IV).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
071849 LED 27 W 120/277 V 70 3000 Type IV - 2520 1857 L70 B10 60000 Download

Documentation: FOCUS+ 2 TYPE IV - 071849
071868 LED 27 W 120/277 V 70 4000 Type IV - 2820 2074 L70 B10 60000 Download

Documentation: FOCUS+ 2 TYPE IV - 071868

Sources

LED 27 W

Product Family

FOCUS+ 1 FOCUS+ 1
FOCUS+ 3 FOCUS+ 3
FOCUS+ ZERO FOCUS+ ZERO
Open filters Close filters
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
