FOCUS+ ZERO

Innovative low-profile landscape flood light series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
- Extra-clear, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Symmetric Extra-Wide light distribution (S/EW).
- Input voltage: 120 V, integral D.O.B. module with surge protection up to 500 V.
- Pre-wired factory sealed cable for external electrical connection included.
- Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
- Technopolymer ground spike accessory available for FOCUS+ ZERO (ordered separately).
- Matching junction box plate optional accessory available (ordered separately).
- 5-year warranty.

FOCUS+ ZERO S/EW

Optic | Symmetric Extra-Wide

Innovative low-profile landscape flood light series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
- Extra-clear, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Symmetric Extra-Wide light distribution (S/EW).
- Input voltage: 120 V, integral D.O.B. module with surge protection up to 500 V.
- Pre-wired factory sealed cable for external electrical connection included.
- Technopolymer ground spike accessory available for FOCUS+ ZERO (ordered separately).
- Matching junction box plate optional accessory available (ordered separately).
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120 V
071971	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071971
071972	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071972
071973	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071973
071974	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071974
071975	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071975
071976	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO S/EW - 071976

Sources

LED

10 W

Optic | Symmetric Extra-Wide

Innovative low-profile landscape flood light series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
- Extra-clear, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Symmetric Extra-Wide light distribution (S/EW).
- Input voltage: 120 V, integral D.O.B. module with surge protection up to 500 V.
- Pre-wired factory sealed cable for external electrical connection included.
- Standard robust ½” NPS knuckle mount with 180° adjustable swivel arm (SA versions) and rugged, locking teeth for a simplified installation.
- Technopolymer ground spike accessory available for FOCUS+ ZERO (ordered separately).
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120 V
070452	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070452
070453	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070453
070454	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070454
070455	LED	10 W	80	4000	-	-	845	712	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070455
070456	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070456
070457	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070457
070458	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070458
070459	LED	10 W	80	3000	-	-	840	630	L70	B10	35000	Documentation: FOCUS+ ZERO SA - 070459

Sources

LED

10 W
