No shadows, just light.
A versatile series of wall luminaires in anti-corrosion die-cast aluminum, with satin, pressed glass diffusers with a frosted internal surface. NIKKO+ is available in three different sizes, with faceplates to protect the diffuser or modify the light output. The luminaire can also be post mounted: posts are extruded aluminum in three different heights, designed to hold one or two luminaires. The post is designed to integrate the fixtures perfectly. The series offers a broad range of lighting solutions for gardens and entryways to residential, commercial or public buildings. With a 10-year glass warranty and the various faceplates/grills, this series is a winner every time.NIKKO+ LA (where LA stands for lantern) gives new life to the classic concept of light present in the collective imagination since the days of Ancient Greece: it makes you feel at home, in a retro but at the same time contemporary environment, instilling a sense of security in the night. Elements of detail and refinement, such as the clear aluminum profile of the structure that shows no signs of welding and the pressed Italian glass, transparent for traditional versions and opal for the LED ones, bring simple elements combined with elegance to amaze in their geometric composition.
Surface-mount doorway and hallway lights and post mount series. Fixtures consist of:
Construction
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • Copper-free (<1%) aluminum extruded post.
  • High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • Custom MCPCB utilized to maximize heat dissipation and promote a long LED lifespan (NIKKO+ 45). High-efficiency COB, combined with an optimized passive cooling system, provides a long LED lifespan (NIKKO+ 21 / 27).
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
Installation
  • Available in three standard sizes of H8.4" x L5.8" (NIKKO+ 21 ), H10.8" x L7.2" (NIKKO+ 27) , H16.7" x L5.8" (NIKKO+ 45) with ring, grill (/G), or visa (/V) faceplate. Overall depth is x 5.2" - 5.6".
  • Wall bracket and post accessories available (ordered separately).
Optics
  • 100% uniform diffused light emission.
Electrical
  • Input voltage: 120-277 V (50 / 60 Hz), integral driver.
Options
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
Listings
  • UL Wet location listed. IP65 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
Warranty
  • 10-year glass warranty.
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
