SHIELD+ 2

  • Long-lasting energy-efficient wall pack series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Specular vacuum metallized polycarbonate reflector provides full-cutoff, no glare design, and precision optical control.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver (37 W / 53 W versions).
  • - Field settable integral bi-level lumen/wattage packages (37 W / 53 W) proprietary DIP switch driver for SHIELD+ 2 (stating factory setting at the lowest level).
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard knock-out template for multiple junction box mounting options.
  • - Suitable for three surface mounted conduit entry points with 1/2" NPS plugs.
  • - BUTTON and SWIVEL 120-277 V (50 / 60 Hz) photoelectric switch options available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
SHIELD+ 2 TYPE III

SHIELD+ 2 TYPE III

Optic | Asymmetric Extra-Wide
  • Long-lasting energy-efficient wall pack series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Specular vacuum metallized polycarbonate reflector provides full-cutoff, no glare design, and precision optical control.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver (37 W / 53 W versions).
  • - Field settable integral bi-level lumen/wattage packages (37 W / 53 W) proprietary DIP switch driver for SHIELD+ 2 (stating factory setting at the lowest level).
  • - Standard knock-out template for multiple junction box mounting options.
  • - Suitable for three surface mounted conduit entry points with 1/2" NPS plugs.
  • - BUTTON and SWIVEL 120-277 V (50 / 60 Hz) photoelectric switch options available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
070444 LED 37/53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070444
070445 LED 37/53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070445
070446 LED 37/53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070446
070447 LED 37/53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070447
High Power LEDS 120-277 V Dimmable 0-10 V
070448 LED 80 W 120/277 V 80 4000 Type III - 10552 7985 L80 B10 75000 Download

Documentation: SHIELD+ 2 TYPE III - 070448
070449 LED 80 W 120/277 V 80 4000 Type III - 10552 7985 L80 B10 75000 Download

Documentation: SHIELD+ 2 TYPE III - 070449
070450 LED 80 W 120/277 V 80 4000 Type III - 10552 7985 L80 B10 75000 Download

Documentation: SHIELD+ 2 TYPE III - 070450
070451 LED 80 W 120/277 V 80 4000 Type III - 10552 7985 L80 B10 75000 Download

Documentation: SHIELD+ 2 TYPE III - 070451
070726 LED 38 W 120/277 V 80 4000 Type III - 5590 4705 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070726
070727 LED 38 W 120/277 V 80 4000 Type III - 5590 4705 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070727
070728 LED 38 W 120/277 V 80 4000 Type III - 5590 4705 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070728
070729 LED 38 W 120/277 V 80 4000 Type III - 5590 4705 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070729
070730 LED 38 W 120/277 V 80 4000 Type III - 5590 4705 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070730
070731 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070731
070732 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070732
070733 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070733
070734 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070734
070735 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+ 2 TYPE III - 070735

Sources

LED 37/53 W
LED 80 W
LED 38 W
LED 53 W
SHIELD+2 TYPE III EMPK

SHIELD+2 TYPE III EMPK

Optic | Asymmetric Extra-Wide
  • Long-lasting energy-efficient wall pack series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Specular vacuum metallized polycarbonate reflector provides full-cutoff, no glare design, and precision optical control.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Standard knock-out template for multiple junction box mounting options.
  • - Suitable for three surface mounted conduit entry points with 1/2" NPS plugs.
  • - BUTTON and SWIVEL 120-277 V (50 / 60 Hz) photoelectric switch options available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V Dimmable 0-10 V
070532 LED 37 W 120/277 V 80 4000 Type III - 5240 4705 L80 B10 200000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070532
070533 LED 37 W 120/277 V 80 4000 Type III - 5240 4705 L80 B10 200000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070533
070534 LED 37 W 120/277 V 80 4000 Type III - 5240 4705 L80 B10 200000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070534
070535 LED 37 W 120/277 V 80 4000 Type III - 5240 4705 L80 B10 200000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070535
070590 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070590
070591 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070591
070592 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070592
070593 LED 53 W 120/277 V 80 4000 Type III - 7210 6070 L80 B10 150000 Download

Documentation: SHIELD+2 TYPE III EMPK - 070593

Sources

LED 37 W
LED 53 W
