Enhance every detail

Artificial light plays an essential role in the environment during night time: it provides orientation, transmits mood and emotions, and draws attention.FOCUS+series offers high performance with LED sources amongst the most efficient and updated In the marketplace. It is a functional and intelligent choice for today's lighting needs. FOCUS+ is an excellent selection of compact floodlights specifically suited to enhance architectural details, illuminate vertical and horizontal surfaces, and other typical structural landscape needs.The range of beam distributions and wattages offers various options to enhance your project.

Long-lasting energy-efficient floodlight series. Fixtures consist of:

Construction

Multi-step powder-coat painting process, optimized against UV rays and corrosion.
Copper-free (<1%) precision die-cast aluminum housing, ring/faceplate, and adjustable mounting arm.
Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
High-transparency polycarbonate optics for optimized light transmission.
Extra-clear, tempered, silk-screened, flat glass diffuser.
Custom molded, anti-aging gasket(s).
Stainless steel external hardware.

Installation

Available in three standard sizes of H5.2" x L3,1" x D1.2" (FOCUS+ ZERO), H8.8" x L6.3" x D1.7" (FOCUS+ 1) and H11.8" x L8.7" x D2" (FOCUS+ 2 / 3).
Pre-wired factory sealed cable for external electrical connection included.
Standard swilvel arm (SA versions) for a simplified installation.
Technopolymer ground spike accessory available for FOCUS+ ZERO (ordered separately).
Matching junction box plate optional accessory available (ordered separately).

Optics

Circular Intensive (C/I), Medium (C/M), Wide (C/W), Elliptical (ELL), NEMA 6H x 7V (ZERO versions), 3H x 7V (Type I), 5H x 6V (Type IV), and 5H x 7V (Type III) optics and light distributions.

Electrical

Input voltage: 120 V, Integral D.O.B. module with surge protection up to 500 V (FOCUS+ ZERO) and 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver (FOCUS+ 1 / 2 / 3).

Options

The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.

Listings

UL Wet location listed. IP65 rated (FOCUS+ ZERO).
UL Wet location listed. IP66 rated.
Product meets Buy American Act (BAA) requirements within ARRA.
Consult factory for which version qualifies for the PRONTO-SHIP program. All Rough-Ins are available to ship within 48-72 hrs. Orders must be marked "PRONTO."
Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.

Warranty

5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
