Rhythm on the wall
The QUASAR family was born from the idea that sometimes all that a project calls for sometimes is the cleanest design. To almost every project that you will find yourself working, this simple fixture in four different sizes could be applied. The QUASAR 10 gives you the dramatic punch you want in a compact package and at a price point. With the chance to customize everything from the beams and apertures to the color of the glass, this is the little fixture that does it all and does it in the most energy-efficient and cost-efficient way. The QUASAR 20, with options for dual or mono distribution, takes a little more uncompromising approach in a slightly bigger body and yet maintains that ability for you to tailor it with a variety of color choices for your unique design needs. The QUASAR 30, wall, and ceiling mount gives you dimming in addition to the unique customized aperture and color opportunities as the smaller versions. The QUASAR 60 rounds out the series with multiple wattage options, an integral 90-minute emergency battery pack, and single and dual emission options. With so much variety in one cost-conscious series, the QUASAR is a choice well made.
Design-coordinated ceiling mount (QUASAR 30 CEILING), wall effect (QUASAR 10) and wall sconce (QUASAR 20 / 30 / 60) series. Fixtures consist of:
Construction
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • High-efficiency COB, combined with an optimized passive cooling system, provides a long LED lifespan (QUASAR 20 / 30). Internal reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection. Custom MCPCB utilized to maximize heat dissipation and promote a long LED lifespan (QUASAR 10 / 60). Extra-clear, flat, tempered silk-screened soda-lime glass diffuser (QUASAR 10). Micro-prismatic patterned, flat, tempered silk-screened soda-lime glass diffuser (QUASAR 20 / 30 / 60).
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
Installation
  • Available in four standard lengths of 4" (QUASAR 10), 8"(QUASAR 20), 12" (QUASAR 30) and 24" (QUASAR 60). Overall standard height of 4" and depth of 4".
  • Junction box mounting plate included (for 4" octagon box only, provided by others).
Optics
  • Surface light-effect emission (QUASAR 10). Type I (QUASAR 20 / 30), Type II (QUASAR 60 M / B), and Type III (QUASAR 60 TECH / DOUBLE TECH) light distributions. Diffuse light emission for ceiling version (QUASAR 30 CEILING).
Electrical
  • Input voltage: 120-277 V (50 / 60 Hz), integral driver (QUASAR 10); 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver (QUASAR 20 / 30 / 60).
Options
  • Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
Listings
  • UL Wet location listed. IP44 rated (QUASAR 10).
  • UL Wet location listed. IP65 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • ADA compliant.
  • Consult factory for which version qualifies for the PRONTO-SHIP program. All Rough-Ins are available to ship within 48-72 hrs. Orders must be marked "PRONTO."
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
Warranty
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
