KHA SLIM 50"

IN
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free aluminum extruded post.
  • - Copper-free precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - IESNA Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom post height options.
  • - Consult factory for HSS and other Shield options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free aluminum extruded post.
  • - Copper-free precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - IESNA Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom post height options.
  • - Consult factory for HSS and other Shield options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
High Power LEDS 120-277 V
076433-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076433-50

076434-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076434-50

076435-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076435-50

076436-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076436-50

076437-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076437-50

076438-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076438-50

076458-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076458-50

076459-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076459-50

076460-50 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076460-50

076461-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076461-50

076462-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076462-50

076463-50 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 50" LED - 076463-50

Sources

LED 50 W
