KHA SLIM 7'2''

IN
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) aluminum extruded post.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) aluminum extruded post.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
076424 LED 14 W 120/277 V 80 3000 - - 1652 482 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076424

076425 LED 14 W 120/277 V 80 3000 - - 1652 482 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076425

076426 LED 14 W 120/277 V 80 3000 - - 1652 482 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076426

076427 LED 14 W 120/277 V 80 4000 - - 1706 546 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076427

076428 LED 14 W 120/277 V 80 4000 - - 1706 546 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076428

076429 LED 14 W 120/277 V 80 4000 - - 1706 546 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076429

076430 LED 14 W 120/277 V 70 5000 - - 1732 592 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076430

076431 LED 14 W 120/277 V 70 5000 - - 1732 592 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076431

076432 LED 14 W 120/277 V 70 5000 - - 1732 592 L80 B10 50000 Download

Documentation: KHA SLIM 7'2'' LED - 076432

Sources

LED 14 W
