KHA 9

Pathway bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Corrosion-resistant AISI 316 stainless steel post and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Anchor bolts available for bollards (ordered separately).
- Suitable for most coastal applications (stainless steel versions).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

KHA 9 LED

Optic | Circular Extra-Wide

Pathway bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Corrosion-resistant AISI 316 stainless steel post and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Anchor bolts available for bollards (ordered separately).
- Suitable for most coastal applications (stainless steel versions).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V
076449	LED	19 W	120/277 V	80	3000	-	-	2308	1182	L70	B10	50000	Documentation: KHA 9 LED - 076449
076450	LED	19 W	120/277 V	80	3000	-	-	2308	1182	L70	B10	50000	Documentation: KHA 9 LED - 076450
076451	LED	19 W	120/277 V	80	3000	-	-	2308	1182	L70	B10	50000	Documentation: KHA 9 LED - 076451
076452	LED	19 W	120/277 V	80	4000	-	-	2384	1356	L70	B10	50000	Documentation: KHA 9 LED - 076452
076453	LED	19 W	120/277 V	80	4000	-	-	2384	1356	L70	B10	50000	Documentation: KHA 9 LED - 076453
076454	LED	19 W	120/277 V	80	4000	-	-	2384	1356	L70	B10	50000	Documentation: KHA 9 LED - 076454
076455	LED	19 W	120/277 V	70	5000	-	-	2420	1379	L70	B10	50000	Documentation: KHA 9 LED - 076455
076456	LED	19 W	120/277 V	70	5000	-	-	2420	1379	L70	B10	50000	Documentation: KHA 9 LED - 076456
076457	LED	19 W	120/277 V	70	5000	-	-	2420	1379	L70	B10	50000	Documentation: KHA 9 LED - 076457
