KHA SLIM 8'

IN
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) aluminum extruded post.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Slim area and site lighting series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) aluminum extruded post.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Suitable for most coastal applications (stainless steel versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
076433 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076433

076434 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076434

076435 LED 50 W 120/277 V 80 3000 Type V - 6695 4914 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076435

076436 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076436

076437 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076437

076438 LED 50 W 120/277 V 80 4000 Type V - 7062 5190 L70 B10 36000 Download

Documentation: KHA SLIM 8' LED - 076438

Sources

LED 50 W
