KHA 5

IN
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and top cap.
  • - Copper-free (<1%) aluminum extruded post.
  • - Corrosion-resistant AISI 316 stainless steel post and top cap.
  • - Clear UV-stabilized, high-impact resistant diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • - High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • - Type V light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Anchor bolts available for bollards (ordered separately).
  • - Suitable for most coastal applications (stainless steel versions).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
076440 LED 19 W 120/277 V 80 3000 - - 2308 1182 L70 B10 50000 Download

Documentation: KHA 5 LED - 076440

076441 LED 19 W 120/277 V 80 3000 - - 2308 1182 L70 B10 50000 Download

Documentation: KHA 5 LED - 076441

076442 LED 19 W 120/277 V 80 3000 - - 2308 1182 L70 B10 50000 Download

Documentation: KHA 5 LED - 076442

076443 LED 19 W 120/277 V 80 4000 - - 2384 1356 L70 B10 50000 Download

Documentation: KHA 5 LED - 076443

076444 LED 19 W 120/277 V 80 4000 - - 2384 1356 L70 B10 50000 Download

Documentation: KHA 5 LED - 076444

076445 LED 19 W 120/277 V 80 4000 - - 2384 1356 L70 B10 50000 Download

Documentation: KHA 5 LED - 076445

076446 LED 19 W 120/277 V 70 5000 - - 2420 1379 L70 B10 50000 Download

Documentation: KHA 5 LED - 076446

076447 LED 19 W 120/277 V 70 5000 - - 2420 1379 L70 B10 50000 Download

Documentation: KHA 5 LED - 076447

076448 LED 19 W 120/277 V 70 5000 - - 2420 1379 L70 B10 50000 Download

Documentation: KHA 5 LED - 076448

Sources

LED 19 W
