KHA SLIM 36''

Slim bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Corrosion-resistant AISI 316 stainless steel post and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Stainless steel external hardware.
- Custom molded, anti-aging gasket(s).
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- nchor bolts available for bollards (ordered separately).
- Suitable for most coastal applications (stainless steel versions).
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

KHA SLIM 36'' LED

Optic | Circular Extra-Wide

Slim bollard series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) aluminum extruded post.
- Copper-free (<1%) precision die-cast aluminum housing and top cap.
- Corrosion-resistant AISI 316 stainless steel post and top cap.
- Clear UV-stabilized, high-impact resistant diffuser.
- Stainless steel external hardware.
- Custom molded, anti-aging gasket(s).
- Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
- High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
- Type V light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- nchor bolts available for bollards (ordered separately).
- Suitable for most coastal applications (stainless steel versions).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V
076415	LED	14 W	120/277 V	80	3000	-	-	1652	482	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076415
076416	LED	14 W	120/277 V	80	3000	-	-	1652	482	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076416
076417	LED	14 W	120/277 V	80	3000	-	-	1652	482	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076417
076418	LED	14 W	120/277 V	80	4000	-	-	1706	546	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076418
076419	LED	14 W	120/277 V	80	4000	-	-	1706	546	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076419
076420	LED	14 W	120/277 V	80	4000	-	-	1706	546	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076420
076421	LED	14 W	120/277 V	70	5000	-	-	1732	592	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076421
076422	LED	14 W	120/277 V	70	5000	-	-	1732	592	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076422
076423	LED	14 W	120/277 V	70	5000	-	-	1732	592	L80	B10	50000	Documentation: KHA SLIM 36'' LED - 076423

Sources

LED

14 W
