INSERT+ ZERO CLIPS GLASS

  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Screen-printed tempered glass front diffuser (GLASS options)
  • - Diffuse light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Mud Ring included for INSERT+ ZERO options (J-Box provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
INSERT+ ZERO CLIPS GLASS

INSERT+ ZERO CLIPS GLASS

Optic | Symmetric Extra-Wide
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Screen-printed tempered glass front diffuser (GLASS options)
  • - Diffuse light emission.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Mud Ring included for INSERT+ ZERO options (J-Box provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
070623 LED 6 W 120/277 V 80 3000 - - 660 107 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS GLASS - 070623
070624 LED 6 W 120/277 V 80 4000 - - 684 119 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS GLASS - 070624
071961 LED 4 W 120/277 V 80 3000 - - 511 81 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS GLASS - 071961
071962 LED 4 W 120/277 V 80 4000 - - 529 89 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS GLASS - 071962
