INSERT+ 2V BOLLARD

IN
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Optional, integral, line-voltage, passive infrared motion sensor (PIR SENSOR versions).
  • - Optional, integral, line-voltage, photoelectric switch sensor (PHOTOCELL versions)
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Aluminum ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Aluminum ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
072138 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 - 072138

072140 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 - 072140

072142 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 - 072142

072144 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 - 072144

Sources

LED 9 W
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Optional, integral, line-voltage, photoelectric switch sensor (PHOTOCELL versions)
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Aluminum ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDs 120-277V Dimmable 0-10V PHOTOCELL
072146 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 PHOTOCELL - 072146

072148 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 PHOTOCELL - 072148

072150 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 PHOTOCELL - 072150

072152 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 PHOTOCELL - 072152

Sources

LED 9 W
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Optional, integral, line-voltage, passive infrared motion sensor (PIR SENSOR versions).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDs 120-277V Dimmable 0-10V PIR SENSOR
072154 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 SENSOR - 072154

072156 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 SENSOR - 072156

072158 LED 9 W 120/277 V 80 3000 - - 1197 592 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 SENSOR - 072158

072160 LED 9 W 120/277 V 80 4000 - - 1318 633 L80 B10 100000 Download

Documentation: INSERT+ 2V BOLLARD 750 SENSOR - 072160

Sources

LED 9 W
