INSERT+3

IN
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, tempered, flat glass diffuser.
  • - Frosted, tempered, flat glass diffuser.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - Suitable for concrete or hollow wall applications.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
INSERT+3

INSERT+3

Asymmetric wide reflector
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Frosted, tempered, flat glass diffuser.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - Suitable for concrete or hollow wall applications.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071981 LED 29 W 120-277 V 80 3000 Type III - 4020 1502 L80 B10 60000 Download

Documentation: INSERT+3 - 071981
071982 LED 29 W 120-277 V 80 4000 Type III - 4140 1592 L80 B10 60000 Download

Documentation: INSERT+3 - 071982
071983 LED 29 W 120-277 V 80 3000 Type III - 4020 1502 L80 B10 60000 Download

Documentation: INSERT+3 - 071983
071984 LED 29 W 120-277 V 80 4000 Type III - 4140 1592 L80 B10 60000 Download

Documentation: INSERT+3 - 071984

Sources

LED 29 W
INSERT+3 TYPE II

INSERT+3 TYPE II

Asymmetric wide reflector
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Extra-clear, tempered, flat glass diffuser.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - Suitable for concrete or hollow wall applications.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
071977 LED 26 W 120-277 V 70 3000 Type II - 3450 1388 L80 B10 125000 Download

Documentation: INSERT+3 TYPE II - 071977
071978 LED 26 W 120-277 V 70 4000 Type II - 3585 1399 L80 B10 125000 Download

Documentation: INSERT+3 TYPE II - 071978
071979 LED 26 W 120-277 V 70 3000 Type II - 3450 1388 L80 B10 125000 Download

Documentation: INSERT+3 TYPE II - 071979
071980 LED 26 W 120-277 V 70 4000 Type II - 3585 1399 L80 B10 125000 Download

Documentation: INSERT+3 TYPE II - 071980

Sources

LED 26 W
