INSERT+ ZERO

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type II light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Mud Ring included for INSERT+ ZERO options (J-Box provided by others).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Optic | Asymmetric Extra-Wide

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type II light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Mud Ring included for INSERT+ ZERO options (J-Box provided by others).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V
070594	LED	6 W	120/277 V	80	3000	-	-	660	188	L80	B10	60000	Documentation: INSERT+ ZERO - 070594
070595	LED	6 W	120/277 V	80	4000	-	-	684	196	L80	B10	60000	Documentation: INSERT+ ZERO - 070595
070596	LED	6 W	120/277 V	80	3000	-	-	660	188	L80	B10	60000	Documentation: INSERT+ ZERO - 070596
070597	LED	6 W	120/277 V	80	4000	-	-	684	196	L80	B10	60000	Documentation: INSERT+ ZERO - 070597
070598	LED	6 W	120/277 V	80	3000	-	-	660	188	L80	B10	60000	Documentation: INSERT+ ZERO - 070598
070599	LED	6 W	120/277 V	80	4000	-	-	684	196	L80	B10	60000	Documentation: INSERT+ ZERO - 070599
071894	LED	4 W	120/277 V	80	3000	-	-	511	140	L80	B10	60000	Documentation: INSERT+ ZERO - 071894
071896	LED	4 W	120/277 V	80	4000	-	-	529	153	L80	B10	60000	Documentation: INSERT+ ZERO - 071896
071898	LED	4 W	120/277 V	80	3000	-	-	511	140	L80	B10	60000	Documentation: INSERT+ ZERO - 071898
071900	LED	4 W	120/277 V	80	4000	-	-	529	153	L80	B10	60000	Documentation: INSERT+ ZERO - 071900
071902	LED	4 W	120/277 V	80	3000	-	-	511	140	L80	B10	60000	Documentation: INSERT+ ZERO - 071902
071904	LED	4 W	120/277 V	80	4000	-	-	529	153	L80	B10	60000	Documentation: INSERT+ ZERO - 071904
