INSERT+ 2V

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Stainless steel recessed rough-in kit to be ordered separately.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Optic | Asymmetric Extra-Wide

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Stainless steel recessed rough-in kit to be ordered separately.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V - Dimmable 0-10 V
072126	LED	9 W	120/277 V	80	3000	-	-	1197	592	L80	B10	100000	Documentation: INSERT+ 2V - 072126
072128	LED	9 W	120/277 V	80	4000	-	-	1318	633	L80	B10	100000	Documentation: INSERT+ 2V - 072128
072130	LED	9 W	120/277 V	80	3000	-	-	1197	592	L80	B10	100000	Documentation: INSERT+ 2V - 072130
072132	LED	9 W	120/277 V	80	4000	-	-	1318	633	L80	B10	100000	Documentation: INSERT+ 2V - 072132
072134	LED	9 W	120/277 V	80	3000	-	-	1197	592	L80	B10	100000	Documentation: INSERT+ 2V - 072134
072136	LED	9 W	120/277 V	80	4000	-	-	1318	633	L80	B10	100000	Documentation: INSERT+ 2V - 072136

Sources

LED

9 W
