INSERT+2

IN
  • Recessed wall or step light series. Fixtures consists of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and trim.
  • - Frosted, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired cable is factory sealed to housing with a cable gland allowing external electrical connections.
  • - Stainless steel recessed rough-in kit available (to be ordered separately).
  • - Consult factory for dimming options, custom finishes and non-catalogued CCT (Kelvin) options.
  • - Consult factory for custom pre-wired factory sealed cable length options.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V
071405 LED 11 W 120/277V 80 3000 - - 1350 503 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071405

071407 LED 11 W 120/277V 80 3000 - - 1350 503 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071407

071409 LED 11 W 120/277V 80 3000 - - 1350 503 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071409

071411 LED 11 W 120/277V 80 4000 - - 1410 553 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071411

071413 LED 11 W 120/277V 80 4000 - - 1410 553 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071413

071415 LED 11 W 120/277V 80 4000 - - 1410 553 L80 B10 60000 Download

Documentation: INSERT+ 2 [11.18”] - 071415

Sources

LED 11 W
