INSERT+ ZERO CLIPS

IN
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Mud Ring included for INSERT+ ZERO / ZERO CLIPS (J-Box provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Recessed wall steplight series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and ring/faceplate.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Mud Ring included for INSERT+ ZERO / ZERO CLIPS (J-Box provided by others).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
Mid Power LEDS 120-277 V
070600 LED 6 W 120/277 V 80 3000 - - 660 217 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070600

070601 LED 6 W 120/277 V 80 4000 - - 684 225 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070601

070602 LED 6 W 120/277 V 80 3000 - - 660 217 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070602

070603 LED 6 W 120/277 V 80 4000 - - 684 225 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070603

070604 LED 6 W 120/277 V 80 3000 - - 660 217 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070604

070605 LED 6 W 120/277 V 80 4000 - - 684 225 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 070605

071906 LED 4 W 120/277 V 80 3000 - - 511 162 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071906

071908 LED 4 W 120/277 V 80 4000 - - 529 178 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071908

071916 LED 4 W 120/277 V 80 3000 - - 511 162 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071916

071918 LED 4 W 120/277 V 80 4000 - - 529 178 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071918

071920 LED 4 W 120/277 V 80 3000 - - 511 162 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071920

071921 LED 4 W 120/277 V 80 4000 - - 529 178 L80 B10 60000 Download

Documentation: INSERT+ ZERO CLIPS - 071921

Sources

LED 6 W
LED 4 W
