It’s all about uniformity
The value of the BLIZ along with attributes such as shape options of a round, square, rectangle; 0-10V dimming, integral EM, HF Occupancy sensor, allows this product family to be integrated into today's commercial projects with ease.Today's construction and design communities demand confidence in quality and options for stringent code compliance. The BLIZ offers unshielded lighting solutions and options which clear the path and make it easy to conform to local codes. Signage options can be added directly on to the glass lens, or, can be laser cut into the various faceplates of the rectangular series.The Post option of the rectangular range allows the design to be carried further into pathways, parks, and city centers. The Grid options, along with our 10-year warranty on the BLIZ glass, make this product one of the most rugged but at the same time most aesthetically pleasing in the industry.
Design-coordinated ceiling-, wall-, and post-mount (BLIZ) series. Fixtures consists of:
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Copper-free (<1%) die-cast aluminum housing, ring, and faceplates.
  • Copper-free aluminum extruded post (BLIZ rectangle only).
  • Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • High transmittance, internally coated, pressed glass diffuser, thermally, and chemically quenched to strengthen the impact resistance and reduce the effect of rapid temperature changes.
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
  • BLIZ overall size of H5.2" x L10.3"; depths vary depending on faceplate: standard/Ring (3.7"), Guard (4.2"), Visa (3.9"), Visa V (3.9") faceplate. BLIZ ROUND is available in two standard sizes of Ø11.9" (ROUND 30) and Ø15.8" (ROUND 40). BLIZ SQUARE 40 overall size of 14" x 14" with standard/Ring D3.5" or Grid D4"(GRILL). BLIZ OVAL overall sizes of H9.8" x L14.8" x D5".
  • Tiltable LED board mounting bracket allows for quick and easy installation (BLIZ rectangle only).
  • 100% uniform diffused light emission.
  • Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • Optional, integral, high-frequency motion-sensor operating at a frequency of 5.8 GHz +/- 75 MHz (HF versions). Standard daylight Photocell function for ROUND and SQUARE options.
  • Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • UL Wet location listed. IP65 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • ADA compliant.
  • Consult factory for which version qualifies for the PRONTO-SHIP program. All Rough-Ins are available to ship within 48-72 hrs. Orders must be marked "PRONTO."
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
  • 10-year glass warranty.
  • 5-year limited warranty. Complete warranty terms located at
