ALU SQUARE 2

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
ALU 2 - 180°

ALU 2 - 180°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079146 LED 4.2 W 80 3000 - - 290 71 - - 60000 ALU 2 - 180° Download

Documentation: ALU 2 - 180° - 079146
079148 LED 4.2 W 80 6000 - - 470 101 - - 60000 ALU 2 - 180° Download

Documentation: ALU 2 - 180° - 079148
079150 LED 4.2 W 80 3000 - - 290 71 - - 60000 ALU 2 - 180° Download

Documentation: ALU 2 - 180° - 079150
079152 LED 4.2 W 80 6000 - - 470 101 - - 60000 ALU 2 - 180° Download

Documentation: ALU 2 - 180° - 079152

Sources

LED 4.2 W
ALU 2 - 180° - 120-277 - 10°X45°

ALU 2 - 180° - 120-277 - 10°X45°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079748 LED 2.7 W 120/277 V 80 3000 - 2 x 10°x45°/180 290 88 - - 60000 ALU 2 - 180° - 120-277 - 10°X45° Download

Documentation: ALU 2 - 180° - 120-277 - 10°X45° - 079748
079750 LED 2.7 W 120/277 V 80 6000 - 2 x 10°x45°/180 470 112 - - 60000 ALU 2 - 180° - 120-277 - 10°X45° Download

Documentation: ALU 2 - 180° - 120-277 - 10°X45° - 079750
079752 LED 2.7 W 120/277 V 80 3000 - 2 x 10°x45°/180 290 88 - - 60000 ALU 2 - 180° - 120-277 - 10°X45° Download

Documentation: ALU 2 - 180° - 120-277 - 10°X45° - 079752
079754 LED 2.7 W 120/277 V 80 6000 - 2 x 10°x45°/180 470 112 - - 60000 ALU 2 - 180° - 120-277 - 10°X45° Download

Documentation: ALU 2 - 180° - 120-277 - 10°X45° - 079754

Sources

LED 2.7 W
ALU 2 - 180° - 120-277 - 40°

ALU 2 - 180° - 120-277 - 40°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079740 LED 2.7 W 120/277 V 80 3000 - 2 x 40°/180 290 106 - - 60000 ALU 2 - 180° - 120-277 - 40° Download

Documentation: ALU 2 - 180° - 120-277 - 40° - 079740
079742 LED 2.7 W 120/277 V 80 6000 - 2 x 40°/180 470 136 - - 60000 ALU 2 - 180° - 120-277 - 40° Download

Documentation: ALU 2 - 180° - 120-277 - 40° - 079742
079744 LED 2.7 W 120/277 V 80 3000 - 2 x 40°/180 290 106 - - 60000 ALU 2 - 180° - 120-277 - 40° Download

Documentation: ALU 2 - 180° - 120-277 - 40° - 079744
079746 LED 2.7 W 120/277 V 80 6000 - 2 x 40°/180 470 136 - - 60000 ALU 2 - 180° - 120-277 - 40° Download

Documentation: ALU 2 - 180° - 120-277 - 40° - 079746

Sources

LED 2.7 W
ALU 2 - 180° - 120-277 - 6°

ALU 2 - 180° - 120-277 - 6°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079724 LED 2.7 W 120/277 V 80 3000 - 2 x 6°/180 290 114 - - 60000 ALU 2 - 180° - 120-277 - 6° Download

Documentation: ALU 2 - 180° - 120-277 - 6° - 079724
079726 LED 2.7 W 120/277 V 80 6000 - 2 x 6°/180 470 147 - - 60000 ALU 2 - 180° - 120-277 - 6° Download

Documentation: ALU 2 - 180° - 120-277 - 6° - 079726
079728 LED 2.7 W 120/277 V 80 3000 - 2 x 6°/180 290 114 - - 60000 ALU 2 - 180° - 120-277 - 6° Download

Documentation: ALU 2 - 180° - 120-277 - 6° - 079728
079730 LED 2.7 W 120/277 V 80 6000 - 2 x 6°/180 470 147 - - 60000 ALU 2 - 180° - 120-277 - 6° Download

Documentation: ALU 2 - 180° - 120-277 - 6° - 079730

Sources

LED 2.7 W
ALU 2 - 180° - 120-277 - 6°+40°

ALU 2 - 180° - 120-277 - 6°+40°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079732 LED 2.7 W 120/277 V 80 3000 - 2 x 6°+40°/180 290 110 - - 60000 ALU 2 - 180° - 120-277 - 6°+40° Download

Documentation: ALU 2 - 180° - 120-277 - 6°+40° - 079732
079734 LED 2.7 W 120/277 V 80 6000 - 2 x 6°+40°/180 470 141 - - 60000 ALU 2 - 180° - 120-277 - 6°+40° Download

Documentation: ALU 2 - 180° - 120-277 - 6°+40° - 079734
079736 LED 2.7 W 120/277 V 80 3000 - 2 x 6°+40°/180 290 110 - - 60000 ALU 2 - 180° - 120-277 - 6°+40° Download

Documentation: ALU 2 - 180° - 120-277 - 6°+40° - 079736
079738 LED 2.7 W 120/277 V 80 6000 - 2 x 6°+40°/180 470 141 - - 60000 ALU 2 - 180° - 120-277 - 6°+40° Download

Documentation: ALU 2 - 180° - 120-277 - 6°+40° - 079738

Sources

LED 2.7 W
ALU 2 - 180° - 40°

ALU 2 - 180° - 40°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Medium optics (C/M).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079122 LED 4.2 W 80 3000 - 2 x 40°/180 290 146 - - 60000 ALU 2 - 180° - 40° Download

Documentation: ALU 2 - 180° - 40° - 079122
079124 LED 4.2 W 80 6000 - 2 x 40°/180 470 200 - - 60000 ALU 2 - 180° - 40° Download

Documentation: ALU 2 - 180° - 40° - 079124
079126 LED 4.2 W 80 3000 - 2 x 40°/180 290 146 - - 60000 ALU 2 - 180° - 40° Download

Documentation: ALU 2 - 180° - 40° - 079126
079128 LED 4.2 W 80 6000 - 2 x 40°/180 470 200 - - 60000 ALU 2 - 180° - 40° Download

Documentation: ALU 2 - 180° - 40° - 079128

Sources

LED 4.2 W
ALU 2 - 180° - 6°

ALU 2 - 180° - 6°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079114 LED 4.2 W 80 3000 - 2 x 6°/180 290 200 - - 60000 ALU 2 - 180° - 6° Download

Documentation: ALU 2 - 180° - 6° - 079114
079116 LED 4.2 W 80 6000 - 2 x 6°/180 470 295 - - 60000 ALU 2 - 180° - 6° Download

Documentation: ALU 2 - 180° - 6° - 079116
079118 LED 4.2 W 80 3000 - 2 x 6°/180 290 200 - - 60000 ALU 2 - 180° - 6° Download

Documentation: ALU 2 - 180° - 6° - 079118
079120 LED 4.2 W 80 6000 - 2 x 6°/180 470 295 - - 60000 ALU 2 - 180° - 6° Download

Documentation: ALU 2 - 180° - 6° - 079120

Sources

LED 4.2 W
ALU 2 - 180° - 6° + 40°

ALU 2 - 180° - 6° + 40°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079130 LED 4.2 W 80 3000 - 2 x 6°+40°/180 290 175 - - 60000 ALU 2 - 180° - 6° + 40° Download

Documentation: ALU 2 - 180° - 6° + 40° - 079130
079132 LED 4.2 W 80 6000 - 2 x 6°+40°/180 470 234 - - 60000 ALU 2 - 180° - 6° + 40° Download

Documentation: ALU 2 - 180° - 6° + 40° - 079132
079134 LED 4.2 W 80 3000 - 2 x 6°+40°/180 290 175 - - 60000 ALU 2 - 180° - 6° + 40° Download

Documentation: ALU 2 - 180° - 6° + 40° - 079134
079136 LED 4.2 W 80 6000 - 2 x 6°+40°/180 470 234 - - 60000 ALU 2 - 180° - 6° + 40° Download

Documentation: ALU 2 - 180° - 6° + 40° - 079136

Sources

LED 4.2 W
ALU 2 - 180°- 10°X45°

ALU 2 - 180°- 10°X45°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Elliptical optics (ELL).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079138 LED 4.2 W 80 3000 - 2 x 10°x45°/180 290 132 - - 60000 ALU 2 - 180°- 10°X45° Download

Documentation: ALU 2 - 180°- 10°X45° - 079138
079140 LED 4.2 W 80 6000 - 2 x 10°x45°/180 470 178 - - 60000 ALU 2 - 180°- 10°X45° Download

Documentation: ALU 2 - 180°- 10°X45° - 079140
079142 LED 4.2 W 80 3000 - 2 x 10°x45°/180 290 132 - - 60000 ALU 2 - 180°- 10°X45° Download

Documentation: ALU 2 - 180°- 10°X45° - 079142
079144 LED 4.2 W 80 6000 - 2 x 10°x45°/180 470 178 - - 60000 ALU 2 - 180°- 10°X45° Download

Documentation: ALU 2 - 180°- 10°X45° - 079144

Sources

LED 4.2 W
ALU 2 - 180° 120-277

ALU 2 - 180° 120-277

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079756 LED 2.7 W 120/277 V 80 3000 - - 290 71 - - 60000 ALU 2 - 180° 120-277 Download

Documentation: ALU 2 - 180° 120-277 - 079756
079758 LED 2.7 W 120/277 V 80 6000 - - 470 101 - - 60000 ALU 2 - 180° 120-277 Download

Documentation: ALU 2 - 180° 120-277 - 079758
079760 LED 2.7 W 120/277 V 80 3000 - - 290 71 - - 60000 ALU 2 - 180° 120-277 Download

Documentation: ALU 2 - 180° 120-277 - 079760
079762 LED 2.7 W 120/277 V 80 6000 - - 470 101 - - 60000 ALU 2 - 180° 120-277 Download

Documentation: ALU 2 - 180° 120-277 - 079762

Sources

LED 2.7 W
ALU 2 - 90°

ALU 2 - 90°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079106 LED 4.2 W 80 3000 - - 290 72 - - 60000 ALU 2 - 90° Download

Documentation: ALU 2 - 90° - 079106
079108 LED 4.2 W 80 6000 - - 470 105 - - 60000 ALU 2 - 90° Download

Documentation: ALU 2 - 90° - 079108
079110 LED 4.2 W 80 3000 - - 290 72 - - 60000 ALU 2 - 90° Download

Documentation: ALU 2 - 90° - 079110
079112 LED 4.2 W 80 6000 - - 470 105 - - 60000 ALU 2 - 90° Download

Documentation: ALU 2 - 90° - 079112

Sources

LED 4.2 W
ALU 2 - 90° - 6°

ALU 2 - 90° - 6°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
079098 LED 4.2 W 80 3000 - 2 x 6°/90 290 168 - - 60000 ALU 2 - 90° - 6° Download

Documentation: ALU 2 - 90° - 6° - 079098
079100 LED 4.2 W 80 6000 - 2 x 6°/90 470 232 - - 60000 ALU 2 - 90° - 6° Download

Documentation: ALU 2 - 90° - 6° - 079100
079102 LED 4.2 W 80 3000 - 2 x 6°/90 290 168 - - 60000 ALU 2 - 90° - 6° Download

Documentation: ALU 2 - 90° - 6° - 079102
079104 LED 4.2 W 80 6000 - 2 x 6°/90 470 232 - - 60000 ALU 2 - 90° - 6° Download

Documentation: ALU 2 - 90° - 6° - 079104

Sources

LED 4.2 W
ALU 2 - 90° 120-277

ALU 2 - 90° 120-277

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079716 LED 2.7 W 120/277 V 80 3000 - - 290 72 - - 60000 ALU 2 - 90° 120-277 Download

Documentation: ALU 2 - 90° 120-277 - 079716
079718 LED 2.7 W 120/277 V 80 6000 - - 470 105 - - 60000 ALU 2 - 90° 120-277 Download

Documentation: ALU 2 - 90° 120-277 - 079718
079720 LED 2.7 W 120/277 V 80 3000 - - 290 72 - - 60000 ALU 2 - 90° 120-277 Download

Documentation: ALU 2 - 90° 120-277 - 079720
079722 LED 2.7 W 120/277 V 80 6000 - - 470 105 - - 60000 ALU 2 - 90° 120-277 Download

Documentation: ALU 2 - 90° 120-277 - 079722

Sources

LED 2.7 W
ALU 2 - 90° 120-277 - 6°

ALU 2 - 90° 120-277 - 6°

  • Wall effect series. Fixtures consist of:
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079708 LED 2.7 W 120/277 V 80 3000 - 2 x 6°/90 290 114 - - 60000 ALU 2 - 90° 120-277 - 6° Download

Documentation: ALU 2 - 90° 120-277 - 6° - 079708
079710 LED 2.7 W 120/277 V 80 6000 - 2 x 6°/90 470 147 - - 60000 ALU 2 - 90° 120-277 - 6° Download

Documentation: ALU 2 - 90° 120-277 - 6° - 079710
079712 LED 2.7 W 120/277 V 80 3000 - 2 x 6°/90 290 114 - - 60000 ALU 2 - 90° 120-277 - 6° Download

Documentation: ALU 2 - 90° 120-277 - 6° - 079712
079714 LED 2.7 W 120/277 V 80 6000 - 2 x 6°/90 470 147 - - 60000 ALU 2 - 90° 120-277 - 6° Download

Documentation: ALU 2 - 90° 120-277 - 6° - 079714

Sources

LED 2.7 W

Product Family

ALU INGROUND ALU INGROUND
ALU LINEAR ALU LINEAR
ALU WALL ALU WALL
ALU ROUND MINI ALU ROUND MINI
ALU SQUARE 1 ALU SQUARE 1
ALU SQUARE 4 ALU SQUARE 4
ALU SQUARE MINI ALU SQUARE MINI
Open filters Close filters
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
