ALU SQUARE 4

IN
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 700 mA
079090 LED 8.4 W 80 3000 - - 580 153 - - 60000 Download

Documentation: ALU 4 - 079090

079092 LED 8.4 W 80 6000 - - 940 215 - - 60000 Download

Documentation: ALU 4 - 079092

079094 LED 8.4 W 80 3000 - - 580 153 - - 60000 Download

Documentation: ALU 4 - 079094

079096 LED 8.4 W 80 6000 - - 940 215 - - 60000 Download

Documentation: ALU 4 - 079096

Sources

LED 8.4 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Elliptical optics (ELL).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 700 mA
079082 LED 8.4 W 80 3000 - 4 x 10°x45°/90 580 277 - - 60000 Download

Documentation: ALU 4 - 10X45° - 079082

079084 LED 8.4 W 80 6000 - 4 x 10°x45°/90 940 364 - - 60000 Download

Documentation: ALU 4 - 10X45° - 079084

079086 LED 8.4 W 80 3000 - 4 x 10°x45°/90 580 277 - - 60000 Download

Documentation: ALU 4 - 10X45° - 079086

079088 LED 8.4 W 80 6000 - 4 x 10°x45°/90 940 364 - - 60000 Download

Documentation: ALU 4 - 10X45° - 079088

Sources

LED 8.4 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
079788 LED 4.6 W 120/277 V 80 3000 - - 580 153 - - 60000 Download

Documentation: ALU 4 - 120-277 - 079788

079790 LED 4.6 W 120/277 V 80 6000 - - 940 215 - - 60000 Download

Documentation: ALU 4 - 120-277 - 079790

079792 LED 4.6 W 120/277 V 80 3000 - - 580 153 - - 60000 Download

Documentation: ALU 4 - 120-277 - 079792

079794 LED 4.6 W 120/277 V 80 6000 - - 940 215 - - 60000 Download

Documentation: ALU 4 - 120-277 - 079794

Sources

LED 4.6 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
079780 LED 4.6 W 120/277 V 80 3000 - 4 x 10°x45°/90 580 176 - - 60000 Download

Documentation: ALU 4 - 120-277 - 10°X45° - 079780

079782 LED 4.6 W 120/277 V 80 6000 - 4 x 10°x45°/90 940 224 - - 60000 Download

Documentation: ALU 4 - 120-277 - 10°X45° - 079782

079784 LED 4.6 W 120/277 V 80 3000 - 4 x 10°x45°/90 580 176 - - 60000 Download

Documentation: ALU 4 - 120-277 - 10°X45° - 079784

079786 LED 4.6 W 120/277 V 80 6000 - 4 x 10°x45°/90 940 224 - - 60000 Download

Documentation: ALU 4 - 120-277 - 10°X45° - 079786

Sources

LED 4.6 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
079772 LED 4.6 W 120/277 V 80 3000 - 4 x 40°/90 580 211 - - 60000 Download

Documentation: ALU 4 - 120-277 - 40° - 079772

079774 LED 4.6 W 120/277 V 80 6000 - 4 x 40°/90 940 271 - - 60000 Download

Documentation: ALU 4 - 120-277 - 40° - 079774

079776 LED 4.6 W 120/277 V 80 3000 - 4 x 40°/90 580 211 - - 60000 Download

Documentation: ALU 4 - 120-277 - 40° - 079776

079778 LED 4.6 W 120/277 V 80 6000 - 4 x 40°/90 940 271 - - 60000 Download

Documentation: ALU 4 - 120-277 - 40° - 079778

Sources

LED 4.6 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
079764 LED 4.6 W 120/277 V 80 3000 - 4 x 6°/90 580 228 - - 60000 Download

Documentation: ALU 4 - 120-277 - 6° - 079764

079766 LED 4.6 W 120/277 V 80 6000 - 4 x 6°/90 940 294 - - 60000 Download

Documentation: ALU 4 - 120-277 - 6° - 079766

079768 LED 4.6 W 120/277 V 80 3000 - 4 x 6°/90 580 228 - - 60000 Download

Documentation: ALU 4 - 120-277 - 6° - 079768

079770 LED 4.6 W 120/277 V 80 6000 - 4 x 6°/90 940 294 - - 60000 Download

Documentation: ALU 4 - 120-277 - 6° - 079770

Sources

LED 4.6 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Medium optics (C/M).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 700 mA
079074 LED 8.4 W 80 3000 - 4 x 40°/90 580 316 - - 60000 Download

Documentation: ALU 4 - 40° - 079074

079076 LED 8.4 W 80 6000 - 4 x 40°/90 940 416 - - 60000 Download

Documentation: ALU 4 - 40° - 079076

079078 LED 8.4 W 80 3000 - 4 x 40°/90 580 316 - - 60000 Download

Documentation: ALU 4 - 40° - 079078

079080 LED 8.4 W 80 6000 - 4 x 40°/90 940 416 - - 60000 Download

Documentation: ALU 4 - 40° - 079080

Sources

LED 8.4 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Surface effects light emission.
  • - Circular Intensive optics (C/I).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 700 mA
079066 LED 8.4 W 80 3000 - 4 x 6°/90 580 354 - - 60000 Download

Documentation: ALU 4 - 6° - 079066

079068 LED 8.4 W 80 6000 - 4 x 6°/90 940 453 - - 60000 Download

Documentation: ALU 4 - 6° - 079068

079070 LED 8.4 W 80 3000 - 4 x 6°/90 580 354 - - 60000 Download

Documentation: ALU 4 - 6° - 079070

079072 LED 8.4 W 80 6000 - 4 x 6°/90 940 453 - - 60000 Download

Documentation: ALU 4 - 6° - 079072

Sources

LED 8.4 W
to top
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
