ALU WALL

IN
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Single (M) or dual (B) light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Single (M) or dual (B) light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
High Power LEDS 700 mA
077361 LED 4.2 W 80 3000 - - 290 112 - - 60000 Download

Documentation: ALU WALL/R B - 077361

077363 LED 4.2 W 80 6000 - - 320 135 - - 60000 Download

Documentation: ALU WALL/R B - 077363

077365 LED 4.2 W 80 3000 - - 290 112 - - 60000 Download

Documentation: ALU WALL/R B - 077365

077367 LED 4.2 W 80 6000 - - 320 135 - - 60000 Download

Documentation: ALU WALL/R B - 077367

Sources

LED 4.2 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Single (M) or dual (B) light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
High Power LEDS 700 mA
077353 LED 2.1 W 80 3000 - - 145 56 - - 60000 Download

Documentation: ALU WALL/R M - 077353

077355 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU WALL/R M - 077355

077357 LED 2.1 W 80 3000 - - 145 56 - - 60000 Download

Documentation: ALU WALL/R M - 077357

077359 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU WALL/R M - 077359

Sources

LED 2.1 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Single (M) or dual (B) light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
High Power LEDS 700 mA
077377 LED 4.2 W 80 3000 - - 290 112 - - 60000 Download

Documentation: ALU WALL/S B - 077377

077379 LED 4.2 W 80 6000 - - 320 135 - - 60000 Download

Documentation: ALU WALL/S B - 077379

077381 LED 4.2 W 80 3000 - - 290 112 - - 60000 Download

Documentation: ALU WALL/S B - 077381

077383 LED 4.2 W 80 6000 - - 320 135 - - 60000 Download

Documentation: ALU WALL/S B - 077383

Sources

LED 4.2 W
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - Single (M) or dual (B) light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
(lm)
Luminaire
lumen
output
(lm)
L B Lifetime Downloads
High Power LEDS 700 mA
077369 LED 2.1 W 80 3000 - - 145 56 - - 60000 Download

Documentation: ALU WALL/S M - 077369

077371 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU WALL/S M - 077371

077373 LED 2.1 W 80 3000 - - 145 56 - - 60000 Download

Documentation: ALU WALL/S M - 077373

077375 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU WALL/S M - 077375

Sources

LED 2.1 W
