ALU LINEAR

IN
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Circular Medium optics (C/M).
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
ALU LINEAR 120-277 - 10°X45°

ALU LINEAR 120-277 - 10°X45°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079178 LED 8.9 W 120/277 V 80 3000 - 10°x45° 435 236 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 10°X45° - 079178
079180 LED 8.9 W 120/277 V 80 6000 - 10°x45° 705 304 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 10°X45° - 079180
079182 LED 8.9 W 120/277 V 80 3000 - 10°x45° 435 236 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 10°X45° - 079182
079184 LED 8.9 W 120/277 V 80 6000 - 10°x45° 705 304 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 10°X45° - 079184

Sources

LED 8.9 W
ALU LINEAR 120-277 - 25°

ALU LINEAR 120-277 - 25°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079162 LED 8.9 W 120/277 V 80 3000 - 25° 435 231 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 25° - 079162
079164 LED 8.9 W 120/277 V 80 6000 - 25° 705 302 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 25° - 079164
079166 LED 8.9 W 120/277 V 80 3000 - 25° 435 231 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 25° - 079166
079168 LED 8.9 W 120/277 V 80 6000 - 25° 705 302 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 25° - 079168

Sources

LED 8.9 W
ALU LINEAR 120-277 - 40°

ALU LINEAR 120-277 - 40°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079170 LED 8.9 W 120/277 V 80 3000 - 40° 435 270 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 40° - 079170
079172 LED 8.9 W 120/277 V 80 6000 - 40° 705 347 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 40° - 079172
079174 LED 8.9 W 120/277 V 80 3000 - 40° 435 270 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 40° - 079174
079176 LED 8.9 W 120/277 V 80 6000 - 40° 705 347 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 40° - 079176

Sources

LED 8.9 W
ALU LINEAR 120-277 - 6°

ALU LINEAR 120-277 - 6°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079154 LED 8.9 W 120/277 V 80 3000 - 6° 435 296 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 6° - 079154
079156 LED 8.9 W 120/277 V 80 6000 - 6° 705 380 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 6° - 079156
079158 LED 8.9 W 120/277 V 80 3000 - 6° 435 296 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 6° - 079158
079160 LED 8.9 W 120/277 V 80 6000 - 6° 705 380 - - 60000 Download

Documentation: ALU LINEAR 120-277 - 6° - 079160

Sources

LED 8.9 W
ALU LINEAR B

ALU LINEAR B

Optic | Symmetric Extra-Wide
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077393 LED 12.6 W 80 3000 - - 510 394 - - 60000 Download

Documentation: ALU LINEAR B - 077393
077395 LED 12.6 W 80 6000 - - 1200 484 - - 60000 Download

Documentation: ALU LINEAR B - 077395
077397 LED 12.6 W 80 3000 - - 510 394 - - 60000 Download

Documentation: ALU LINEAR B - 077397
077399 LED 12.6 W 80 6000 - - 1200 484 - - 60000 Download

Documentation: ALU LINEAR B - 077399

Sources

LED 12.6 W
ALU LINEAR B 120-277 - 10°X45°

ALU LINEAR B 120-277 - 10°X45°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Elliptical optics (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079524 LED 14 W 120/277 V 80 3000 - 10°x45° 870 470 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 10°X45° - 079524
079526 LED 14 W 120/277 V 80 6000 - 10°x45° 1410 609 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 10°X45° - 079526
079528 LED 14 W 120/277 V 80 3000 - 10°x45° 870 470 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 10°X45° - 079528
079530 LED 14 W 120/277 V 80 6000 - 10°x45° 1410 609 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 10°X45° - 079530

Sources

LED 14 W
ALU LINEAR B 120-277 - 25°

ALU LINEAR B 120-277 - 25°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079540 LED 14 W 120/277 V 80 3000 - 25° 870 462 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 25° - 079540
079542 LED 14 W 120/277 V 80 6000 - 25° 1410 604 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 25° - 079542
079544 LED 14 W 120/277 V 80 3000 - 25° 870 462 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 25° - 079544
079546 LED 14 W 120/277 V 80 6000 - 25° 1410 604 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 25° - 079546

Sources

LED 14 W
ALU LINEAR B 120-277 - 40°

ALU LINEAR B 120-277 - 40°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Medium optics (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079532 LED 14 W 120/277 V 80 3000 - 40° 870 539 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 40° - 079532
079534 LED 14 W 120/277 V 80 6000 - 40° 1410 694 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 40° - 079534
079536 LED 14 W 120/277 V 80 3000 - 40° 870 539 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 40° - 079536
079538 LED 14 W 120/277 V 80 6000 - 40° 1410 694 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 40° - 079538

Sources

LED 14 W
ALU LINEAR B 120-277 - 6°

ALU LINEAR B 120-277 - 6°

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 120-277 V
079516 LED 14 W 120/277 V 80 3000 - 6° 870 593 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 6° - 079516
079518 LED 14 W 120/277 V 80 6000 - 6° 1410 761 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 6° - 079518
079520 LED 14 W 120/277 V 80 3000 - 6° 870 593 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 6° - 079520
079522 LED 14 W 120/277 V 80 6000 - 6° 1410 761 - - 60000 Download

Documentation: ALU LINEAR B 120-277 - 6° - 079522

Sources

LED 14 W
ALU LINEAR M

ALU LINEAR M

Optic | Symmetric Extra-Wide
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Single (M) or dual (B) light emission.
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077385 LED 6.3 W 80 3000 - - 433 197 - - 60000 Download

Documentation: ALU LINEAR M - 077385
077387 LED 6.3 W 80 6000 - - 600 242 - - 60000 Download

Documentation: ALU LINEAR M - 077387
077389 LED 6.3 W 80 3000 - - 433 197 - - 60000 Download

Documentation: ALU LINEAR M - 077389
077391 LED 6.3 W 80 6000 - - 600 242 - - 60000 Download

Documentation: ALU LINEAR M - 077391

Sources

LED 6.3 W

Product Family

ALU INGROUND ALU INGROUND
ALU WALL ALU WALL
ALU ROUND MINI ALU ROUND MINI
ALU SQUARE 1 ALU SQUARE 1
ALU SQUARE 2 ALU SQUARE 2
ALU SQUARE 4 ALU SQUARE 4
ALU SQUARE MINI ALU SQUARE MINI
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
