ALU SQUARE 1

IN
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 6° x 6° beam angle (C/I).
  • - 25° x 25° beam angle (C/M).
  • - 40° x 40° beam angle (C/M).
  • - 10° x 45° beam angle (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - For models not in the "120-277" category, a 700 mA constant current driver is available as an accessory or by others (to be remoted). Consult factory for more information.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
ALU 1 - 10°X45°

ALU 1 - 10°X45°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 10° x 45° beam angle (ELL).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - For models not in the "120-277" category, a 700 mA constant current driver is available as an accessory or by others (to be remoted). Consult factory for more information.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 700 mA
079058 LED 2.1 W 700 mA 80 3000 - 10°x45° 145 67 - - 60000 Download

Documentation: ALU 1 - 10°X45° - 079058
079060 LED 2.1 W 700 mA 80 6000 - 10°x45° 235 98 - - 60000 Download

Documentation: ALU 1 - 10°X45° - 079060
079062 LED 2.1 W 700 mA 80 3000 - 10°x45° 145 67 - - 60000 Download

Documentation: ALU 1 - 10°X45° - 079062
079064 LED 2.1 W 700 mA 80 6000 - 10°x45° 235 98 - - 60000 Download

Documentation: ALU 1 - 10°X45° - 079064

Sources

LED 2.1 W
ALU 1 - 25°

ALU 1 - 25°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 25° x 25° beam angle (C/M).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - For models not in the "120-277" category, a 700 mA constant current driver is available as an accessory or by others (to be remoted). Consult factory for more information.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 700 mA
079042 LED 2.1 W 700 mA 80 3000 - 25° 145 68 - - 60000 Download

Documentation: ALU 1 - 25° - 079042
079044 LED 2.1 W 700 mA 80 6000 - 25° 235 91 - - 60000 Download

Documentation: ALU 1 - 25° - 079044
079046 LED 2.1 W 700 mA 80 3000 - 25° 145 68 - - 60000 Download

Documentation: ALU 1 - 25° - 079046
079048 LED 2.1 W 700 mA 80 6000 - 25° 235 91 - - 60000 Download

Documentation: ALU 1 - 25° - 079048

Sources

LED 2.1 W
ALU 1 - 40°

ALU 1 - 40°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 40° x 40° beam angle (C/M).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - For models not in the "120-277" category, a 700 mA constant current driver is available as an accessory or by others (to be remoted). Consult factory for more information.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 700 mA
079050 LED 2.1 W 700 mA 80 3000 - 40° 145 76 - - 60000 Download

Documentation: ALU 1 - 40° - 079050
079052 LED 2.1 W 700 mA 80 6000 - 40° 235 111 - - 60000 Download

Documentation: ALU 1 - 40° - 079052
079054 LED 2.1 W 700 mA 80 3000 - 40° 145 76 - - 60000 Download

Documentation: ALU 1 - 40° - 079054
079056 LED 2.1 W 700 mA 80 6000 - 40° 235 111 - - 60000 Download

Documentation: ALU 1 - 40° - 079056

Sources

LED 2.1 W
ALU 1 - 6°

ALU 1 - 6°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 6° x 6° beam angle (C/I).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - For models not in the "120-277" category, a 700 mA constant current driver is available as an accessory or by others (to be remoted). Consult factory for more information.
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 700 mA
079034 LED 2.1 W 700 mA 80 3000 - 6° 145 85 - - 60000 Download

Documentation: ALU 1 - 6° - 079034
079036 LED 2.1 W 700 mA 80 6000 - 6° 235 111 - - 60000 Download

Documentation: ALU 1 - 6° - 079036
079038 LED 2.1 W 700 mA 80 3000 - 6° 145 85 - - 60000 Download

Documentation: ALU 1 - 6° - 079038
079040 LED 2.1 W 700 mA 80 6000 - 6° 235 111 - - 60000 Download

Documentation: ALU 1 - 6° - 079040

Sources

LED 2.1 W
ALU 1 120-277 - 10°X45°

ALU 1 120-277 - 10°X45°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 10° x 45° beam angle (ELL).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
079700 LED 1.8 W 120-277 V 80 3000 - 10°x45° 145 44 - - 60000 Download

Documentation: ALU 1 120-277 - 10°X45° - 079700
079702 LED 1.8 W 120-277 V 80 6000 - 10°x45° 235 56 - - 60000 Download

Documentation: ALU 1 120-277 - 10°X45° - 079702
079704 LED 1.8 W 120-277 V 80 3000 - 10°x45° 145 44 - - 60000 Download

Documentation: ALU 1 120-277 - 10°X45° - 079704
079706 LED 1.8 W 120-277 V 80 6000 - 10°x45° 235 56 - - 60000 Download

Documentation: ALU 1 120-277 - 10°X45° - 079706

Sources

LED 1.8 W
ALU 1 120-277 - 25°

ALU 1 120-277 - 25°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 25° x 25° beam angle (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
079684 LED 1.8 W 120-277 V 80 3000 - 25° 145 39 - - 60000 Download

Documentation: ALU 1 120-277 - 25° - 079684
079686 LED 1.8 W 120-277 V 80 6000 - 25° 235 50 - - 60000 Download

Documentation: ALU 1 120-277 - 25° - 079686
079688 LED 1.8 W 120-277 V 80 3000 - 25° 145 39 - - 60000 Download

Documentation: ALU 1 120-277 - 25° - 079688
079690 LED 1.8 W 120-277 V 80 6000 - 25° 235 50 - - 60000 Download

Documentation: ALU 1 120-277 - 25° - 079690

Sources

LED 1.8 W
ALU 1 120-277 - 40°

ALU 1 120-277 - 40°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 40° x 40° beam angle (C/M).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
079692 LED 1.8 W 120-277 V 80 3000 - 40° 145 53 - - 60000 Download

Documentation: ALU 1 120-277 - 40° - 079692
079694 LED 1.8 W 120-277 V 80 6000 - 40° 235 68 - - 60000 Download

Documentation: ALU 1 120-277 - 40° - 079694
079696 LED 1.8 W 120-277 V 80 3000 - 40° 145 53 - - 60000 Download

Documentation: ALU 1 120-277 - 40° - 079696
079698 LED 1.8 W 120-277 V 80 6000 - 40° 235 68 - - 60000 Download

Documentation: ALU 1 120-277 - 40° - 079698

Sources

LED 1.8 W
ALU 1 120-277 - 6°

ALU 1 120-277 - 6°

  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Clear UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Wall effects light emission.
  • - 6° x 6° beam angle (C/I).
  • - Input voltage is 120-277 V (50/60 Hz), integral driver for "120-277" models only.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Five optional finishes available. Add finish suffix to any part number for textured Black (BK-81), Iron gray (AN96-96), Aluminum metallic (GR-94), White (WH-87), Iron rust (RB-10) when not standard.
  • - Consult factory for dimming options, marine-grade, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options including static colors.
  • - Consult factory for custom optics options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
High Power LEDS 120-277 V
079676 LED 1.8 W 120-277 V 80 3000 - 6° 145 57 - - 60000 Download

Documentation: ALU 1 120-277 - 6° - 079676
079678 LED 1.8 W 120-277 V 80 6000 - 6° 235 74 - - 60000 Download

Documentation: ALU 1 120-277 - 6° - 079678
079680 LED 1.8 W 120-277 V 80 3000 - 6° 145 57 - - 60000 Download

Documentation: ALU 1 120-277 - 6° - 079680
079682 LED 1.8 W 120-277 V 80 6000 - 6° 235 74 - - 60000 Download

Documentation: ALU 1 120-277 - 6° - 079682

Sources

LED 1.8 W

Product Family

ALU INGROUND ALU INGROUND
ALU LINEAR ALU LINEAR
ALU WALL ALU WALL
ALU ROUND MINI ALU ROUND MINI
ALU SQUARE 2 ALU SQUARE 2
ALU SQUARE 4 ALU SQUARE 4
ALU SQUARE MINI ALU SQUARE MINI
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
