ALU ROUND MINI

IN
  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Matching junction box plate optional accessory available (ordered separately).
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
ALU ROUND FULL

ALU ROUND FULL

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077275 LED 2.1 W 80 3000 - - 145 64 - - 60000 Download

Documentation: ALU ROUND FULL - 077275
077277 LED 2.1 W 80 6000 - - 160 76 - - 60000 Download

Documentation: ALU ROUND FULL - 077277
077279 LED 2.1 W 80 3000 - - 145 64 - - 60000 Download

Documentation: ALU ROUND FULL - 077279
077281 LED 2.1 W 80 6000 - - 160 76 - - 60000 Download

Documentation: ALU ROUND FULL - 077281

Sources

LED 2.1 W
ALU ROUND SHADE

ALU ROUND SHADE

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077289 LED 2.1 W 80 3000 - - 145 54 - - 60000 Download

Documentation: ALU ROUND SHADE - 077289
077291 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU ROUND SHADE - 077291
077293 LED 2.1 W 80 3000 - - 145 54 - - 60000 Download

Documentation: ALU ROUND SHADE - 077293
077295 LED 2.1 W 80 6000 - - 160 68 - - 60000 Download

Documentation: ALU ROUND SHADE - 077295

Sources

LED 2.1 W
ALU ROUND SIDE 1

ALU ROUND SIDE 1

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077297 LED 2.1 W 80 3000 - - 145 24 - - 60000 Download

Documentation: ALU ROUND SIDE 1 - 077297
077299 LED 2.1 W 80 6000 - - 160 29 - - 60000 Download

Documentation: ALU ROUND SIDE 1 - 077299
077301 LED 2.1 W 80 3000 - - 145 24 - - 60000 Download

Documentation: ALU ROUND SIDE 1 - 077301
077303 LED 2.1 W 80 6000 - - 160 29 - - 60000 Download

Documentation: ALU ROUND SIDE 1 - 077303

Sources

LED 2.1 W
ALU ROUND SIDE 4

ALU ROUND SIDE 4

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077305 LED 2.1 W 80 3000 - - 145 17 - - 60000 Download

Documentation: ALU ROUND SIDE 4 - 077305
077307 LED 2.1 W 80 6000 - - 160 22 - - 60000 Download

Documentation: ALU ROUND SIDE 4 - 077307
077309 LED 2.1 W 80 3000 - - 145 17 - - 60000 Download

Documentation: ALU ROUND SIDE 4 - 077309
077311 LED 2.1 W 80 6000 - - 160 22 - - 60000 Download

Documentation: ALU ROUND SIDE 4 - 077311

Sources

LED 2.1 W
ALU ROUND TRIM

ALU ROUND TRIM

  • Wall effect series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision machined anodized aluminum housing and optical compartment.
  • - Satin UV-stabilized diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Surface effects light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Matching junction box plate optional accessory available (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
High Power LEDS 700 mA
077260 LED 2.1 W 80 6000 - - 160 78 - - 60000 Download

Documentation: ALU ROUND TRIM - 077260
077283 LED 2.1 W 80 3000 - - 145 67 - - 60000 Download

Documentation: ALU ROUND TRIM - 077283
077285 LED 2.1 W 80 3000 - - 145 67 - - 60000 Download

Documentation: ALU ROUND TRIM - 077285
077287 LED 2.1 W 80 6000 - - 160 78 - - 60000 Download

Documentation: ALU ROUND TRIM - 077287

Sources

LED 2.1 W
