ALU INGROUND

IN
  • In-ground series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
ALU INGROUND ROUND

ALU INGROUND ROUND

  • In-ground series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
(lm)		 Luminaire
lumen
output
(lm)		 L B Lifetime Downloads
High Power LEDS 700 mA
079018 LED 2.1 W 80 3000 - - 145 13 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079018
079020 LED 2.1 W 80 6000 - - 235 17 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079020
079022 LED 2.1 W 80 3000 - - 145 13 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079022
079024 LED 2.1 W 80 6000 - - 235 17 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079024
079268 LED 2.1 W 80 4000 - - 205 20 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079268
079270 LED 2.1 W 80 4000 - - 205 20 - - 60000 Download

Documentation: ALU INGROUND ROUND - 079270

Sources

LED 2.1 W
ALU INGROUND SQUARE

ALU INGROUND SQUARE

  • In-ground series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision machined anodized aluminum housing and optical compartment.
  • - Frosted, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Diffuse light emission.
  • - To be used with a low-voltage, constant-current (700 mA) driver (ordered separately, consult factory for more information).
  • - Stainless steel recessed rough-in kit to be ordered separately.
  • - For outdoor inground applications, provide drainage gravel at least 12" below the rough-in or a suitable drainage system.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
(lm)		 Luminaire
lumen
output
(lm)		 L B Lifetime Downloads
High Power LEDS 700 mA
079026 LED 2.1 W 80 3000 - - 145 16 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079026
079028 LED 2.1 W 80 6000 - - 235 20 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079028
079030 LED 2.1 W 80 3000 - - 145 16 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079030
079032 LED 2.1 W 80 6000 - - 235 20 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079032
079272 LED 2.1 W 80 4000 - - 205 21 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079272
079274 LED 2.1 W 80 4000 - - 205 21 - - 60000 Download

Documentation: ALU INGROUND SQUARE - 079274

Sources

LED 2.1 W
