Lighting for pathways of all shapes and sizes
KHA and KHA TECH bollard family offers contemporary aesthetics with several dark-sky friendly (no uplight/pollution) options, suitable for private residential and public area lighting such as parks, gardens, and commercial complexes. Available in two standard heights, the stainless steel or extruded powder-coated aluminum bollards (available in five standard finishes or any RAL color) can be paired with a range of accessories, including Hause Side shield. The seamless engineering of housing and reflector design, complete cut-off and fully shielded, and a suitable application of pole height and environment make this series ideal for areas where uplight is restricted or not desired.KHA SLIM are contemporary high-performance bollards and light columns, combining style with a robust design manufactured in high-quality materials and finishing. KHA SLIM products provide functional and dramatic effect lighting with aesthetics suitable for entrances, paths, walkways, courtyards, gardens, public areas, and security lighting. Consult factory for more options such as individual heights and house side shield options. Also available upon request are wall mount versions, “window “versions, and perforated shielding options, among many others.
Design coordinated area lighting column and bollard series. Fixtures consist of:
Construction
  • Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • Corrosion-resistant AISI 316 stainless steel post and top cap.
  • Copper-free precision die-cast aluminum housing, top cap and copper-free aluminum extruded post (Iron Gray and Textured Black versions).
  • Internal reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection. Clear UV-stabilized, high-impact resistant diffuser (KHA - KHA SLIM 36" / 7'2"). High-efficiency COB and an optimized passive cooling system provide a long LED lifespan (KHA 5 / 9). Custom MCPCB utilized to maximize heat dissipation and promote a long LED lifespan (KHA TECH 5 / 9 - KHA SLIM). Satin UV-stabilized diffuser (KHA SLIM 8' / 50" only).
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
Installation
  • Available in six standard heights of 22" and 35" (KHA, KHA TECH) 36", 50", 7'2'', and 8'(KHA SLIM).
  • Anchor bolts available for bollards (ordered separately).
  • Suitable for most coastal applications (stainless steel versions).
Optics
  • Type V overall light distribution (KHA - KHA TECH) and diffuse light emission (KHA SLIM 8' / 50" only).
Electrical
  • Input voltage: 120-277 V (50 / 60 Hz), integral driver.
Options
  • 3857. Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver (KHA TECH options only).
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
Listings
  • UL Wet location listed. IP66 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Consult factory for which version qualifies for the PRONTO-SHIP program. All Rough-Ins are available to ship within 48-72 hrs. Orders must be marked "PRONTO."
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
Warranty
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
