MIMIK 30

IN
  • Wall- and post- mount series. Fixtures consists of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, flat, tempered silk screened soda-lime glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution (FLAT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (to be ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
070000 LED 20 W 120-277V 80 3000 Type II - 2184 1506 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070000

070001 LED 20 W 120-277V 80 3000 Type II - 2184 1506 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070001

070002 LED 20 W 120-277V 80 3000 Type II - 2184 1506 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070002

070004 LED 20 W 120-277V 80 4000 Type II - 2352 1597 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070004

070005 LED 20 W 120-277V 80 4000 Type II - 2352 1597 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070005

070024 LED 20 W 120-277V 80 4000 Type II - 2352 1597 L80 B10 60000 Download

Documentation: MIMIK 30 FLAT M - 070024

Sources

LED 20 W
  • Wall- and post- mount series. Fixtures consists of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (to be ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070006 LED 36 W 120-277V 70 3000 Type II - 3760 2549 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070006

070007 LED 36 W 120-277V 70 3000 Type II - 3760 2549 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070007

070008 LED 36 W 120-277V 70 3000 Type II - 3760 2549 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070008

070009 LED 36 W 120-277V 70 4000 Type II - 4160 2750 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070009

070010 LED 36 W 120-277V 70 4000 Type II - 4160 2750 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070010

070011 LED 36 W 120-277V 70 4000 Type II - 4160 2750 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE II - 070011

Sources

LED 36 W
  • Wall- and post- mount series. Fixtures consists of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (to be ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070012 LED 36 W 120-277V 70 3000 Type III - 3760 2603 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070012

070013 LED 36 W 120-277V 70 3000 Type III - 3760 2603 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070013

070014 LED 36 W 120-277V 70 3000 Type III - 3760 2603 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070014

070015 LED 36 W 120-277V 70 4000 Type III - 4160 2803 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070015

070016 LED 36 W 120-277V 70 4000 Type III - 4160 2803 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070016

070017 LED 36 W 120-277V 70 4000 Type III - 4160 2803 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE III - 070017

Sources

LED 36 W
  • Wall- and post- mount series. Fixtures consists of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type IV light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (to be ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
070018 LED 36 W 120-277V 70 3000 Type IV - 3760 2415 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070018

070019 LED 36 W 120-277V 70 3000 Type IV - 3760 2415 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070019

070020 LED 36 W 120-277V 70 3000 Type IV - 3760 2415 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070020

070021 LED 36 W 120-277V 70 4000 Type IV - 4160 2602 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070021

070022 LED 36 W 120-277V 70 4000 Type IV - 4160 2602 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070022

070023 LED 36 W 120-277V 70 4000 Type IV - 4160 2602 L80 B10 60000 Download

Documentation: MIMIK 30 M TYPE IV - 070023

Sources

LED 36 W
