MIMIK 10

IN
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Single (M) or dual (B) light emission.
  • - Type III light distribution (FLAT).
  • - Type III light distribution.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Customizing facade faceplate available for various versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Single (M) or dual (B) light emission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
071750 LED 10 W 120/277 V 70 3000 - 20° 1424 779 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071750

071752 LED 10 W 120/277 V 70 3000 - 20° 1424 779 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071752

071753 LED 10 W 120/277 V 70 3000 - 20° 1424 779 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071753

071754 LED 10 W 120/277 V 70 4000 - 20° 1566 888 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071754

071755 LED 10 W 120/277 V 70 4000 - 20° 1566 888 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071755

071756 LED 10 W 120/277 V 70 4000 - 20° 1566 888 L80 B10 60000 Download

Documentation: MIMIK 10 B C/I - 071756

Sources

LED 10 W
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Single (M) or dual (B) light emission.
  • - Type III light distribution.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
071739 LED 10 W 120/277 V 70 3000 - - 1424 707 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071739

071740 LED 10 W 120/277 V 70 3000 - - 1424 707 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071740

071742 LED 10 W 120/277 V 70 3000 - - 1424 707 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071742

071744 LED 10 W 120/277 V 70 4000 - - 1566 806 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071744

071746 LED 10 W 120/277 V 70 4000 - - 1566 806 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071746

071748 LED 10 W 120/277 V 70 4000 - - 1566 806 L80 B10 60000 Download

Documentation: MIMIK 10 B TYPE III + C/I - 071748

Sources

LED 10 W
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type III light distribution (FLAT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Customizing facade faceplate available for various versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V
071502 LED 10 W 120/277 V 80 3000 - - 1190 880 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071502

071504 LED 10 W 120/277 V 80 3000 - - 1190 880 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071504

071506 LED 10 W 120/277 V 80 3000 - - 1190 880 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071506

071520 LED 10 W 120/277 V 80 4000 - - 1302 925 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071520

071522 LED 10 W 120/277 V 80 4000 - - 1302 925 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071522

071524 LED 10 W 120/277 V 80 4000 - - 1302 925 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT B - 071524

Sources

LED 10 W
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Single (M) or dual (B) light emission.
  • - Type III light distribution (FLAT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Customizing facade faceplate available for various versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
Mid Power LEDS 120-277 V
071489 LED 5 W 120/277 V 80 3000 - - 595 451 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071489

071490 LED 5 W 120/277 V 80 3000 - - 595 451 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071490

071491 LED 5 W 120/277 V 80 3000 - - 595 451 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071491

071492 LED 5 W 120/277 V 80 4000 - - 651 473 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071492

071493 LED 5 W 120/277 V 80 4000 - - 651 473 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071493

071494 LED 5 W 120/277 V 80 4000 - - 651 473 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071494

071495 LED 10 W 120/277 V 80 3000 - - 1020 771 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071495

071496 LED 10 W 120/277 V 80 3000 - - 1020 771 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071496

071497 LED 10 W 120/277 V 80 3000 - - 1020 771 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071497

071498 LED 10 W 120/277 V 80 4000 - - 1110 810 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071498

071499 LED 10 W 120/277 V 80 4000 - - 1110 810 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071499

071500 LED 10 W 120/277 V 80 4000 - - 1110 810 L80 B10 54000 Download

Documentation: MIMIK 10 FLAT M - 071500

Sources

LED 5 W
LED 10 W
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Circular Intensive optics (C/I).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
071568 LED 5 W 120/277 V 70 3000 - 20° 712 379 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071568

071722 LED 5 W 120/277 V 70 3000 - 20° 712 379 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071722

071723 LED 5 W 120/277 V 70 3000 - 20° 712 379 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071723

071724 LED 5 W 120/277 V 70 4000 - 20° 783 432 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071724

071725 LED 5 W 120/277 V 70 4000 - 20° 783 432 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071725

071726 LED 5 W 120/277 V 70 4000 - 20° 783 432 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071726

071733 LED 10 W 120/277 V 70 3000 - 20° 1000 653 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071733

071734 LED 10 W 120/277 V 70 3000 - 20° 1000 653 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071734

071735 LED 10 W 120/277 V 70 3000 - 20° 1000 653 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071735

071736 LED 10 W 120/277 V 70 4000 - 20° 1100 745 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071736

071737 LED 10 W 120/277 V 70 4000 - 20° 1100 745 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071737

071738 LED 10 W 120/277 V 70 4000 - 20° 1100 745 L80 B10 60000 Download

Documentation: MIMIK 10 M C/I - 071738

Sources

LED 5 W
LED 10 W
  • Wall sconce series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - High-transparency polycarbonate optics for optimized light transmission.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle
Lightsource
lumen
output
[lm]
Luminaire
lumen
output
[lm]
L B Lifetime Downloads
High Power LEDS 120-277 V
071532 LED 5 W 120/277 V 70 3000 Type III - 712 314 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071532

071534 LED 5 W 120/277 V 70 3000 Type III - 712 314 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071534

071536 LED 5 W 120/277 V 70 3000 Type III - 712 314 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071536

071538 LED 5 W 120/277 V 70 4000 Type III - 783 358 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071538

071540 LED 5 W 120/277 V 70 4000 Type III - 783 358 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071540

071542 LED 5 W 120/277 V 70 4000 Type III - 783 358 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071542

071727 LED 10 W 120/277 V 70 3000 Type III - 1000 542 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071727

071728 LED 10 W 120/277 V 70 3000 Type III - 1000 542 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071728

071729 LED 10 W 120/277 V 70 3000 Type III - 1000 542 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071729

071730 LED 10 W 120/277 V 70 4000 Type III - 1100 617 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071730

071731 LED 10 W 120/277 V 70 4000 Type III - 1100 617 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071731

071732 LED 10 W 120/277 V 70 4000 Type III - 1100 617 L80 B10 60000 Download

Documentation: MIMIK 10 M TYPE III - 071732

Sources

LED 5 W
LED 10 W
to top
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
