MIMIK 10 CEILING

Ceiling mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
- Extra-clear, tempered, silk-screened, flat glass diffuser.
- Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (TECH versions).
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- High-transparency polycarbonate optics for optimized light transmission.
- Circular Intensive optics (C/I).
- Diffuse light emission (TECH).
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

MIMIK 10 CEILING C/I

Optic | Circular Intensive

Ceiling mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
- Extra-clear, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- High-transparency polycarbonate optics for optimized light transmission.
- Circular Intensive optics (C/I).
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V
071757	LED	10 W	120/277 V	70	3000	-	20°	1000	600	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071757
071758	LED	10 W	120/277 V	70	3000	-	20°	1000	600	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071758
071759	LED	10 W	120/277 V	70	3000	-	20°	1000	600	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071759
071760	LED	10 W	120/277 V	70	4000	-	20°	1100	690	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071760
071761	LED	10 W	120/277 V	70	4000	-	20°	1100	690	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071761
071762	LED	10 W	120/277 V	70	4000	-	20°	1100	690	L80	B10	60000	Documentation: MIMIK 10 CEILING C/I - 071762

Sources

LED

10 W

Ceiling mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
- Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (TECH versions).
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Diffuse light emission (TECH).
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
High Power LEDS 120-277 V
071763	LED	10 W	120/277 V	70	3000	-	-	1000	701	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071763
071764	LED	10 W	120/277 V	70	3000	-	-	1000	701	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071764
071765	LED	10 W	120/277 V	70	3000	-	-	1000	701	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071765
071766	LED	10 W	120/277 V	70	4000	-	-	1100	806	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071766
071767	LED	10 W	120/277 V	70	4000	-	-	1100	806	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071767
071769	LED	10 W	120/277 V	70	4000	-	-	1100	806	L80	B10	60000	Documentation: MIMIK 10 CEILING TECH - 071769
