MIMIK 20 CEILING

Ceiling- and wall- mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
- Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (FLAT versions).
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Symmetric Extra-Wide light distribution (S/EW).
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Optic | Symmetric Extra-Wide

Ceiling- and wall- mount series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and mounting plate.
- Micro-prismatic patterned, tempered, silk-screened, flat glass diffuser (FLAT versions).
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Symmetric Extra-Wide light distribution (S/EW).
- Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Contact factory for any Buy American Act (BAA) or Build America Buy America Act (BABAA) requirements.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V Dimmable 0-10 V
079943	LED	24 W	120/277 V	80	3000	-	-	3335	1869	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079943
079944	LED	24 W	120/277 V	80	4000	-	-	3560	1918	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079944
079945	LED	24 W	120/277 V	80	3000	-	-	3335	1869	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079945
079946	LED	24 W	120/277 V	80	4000	-	-	3560	1918	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079946
079947	LED	24 W	120/277 V	80	3000	-	-	3335	1869	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079947
079948	LED	24 W	120/277 V	80	4000	-	-	3560	1918	L80	B10	84000	Documentation: MIMIK 20 CEILING - 079948
