MIMIK 20

IN
  • Wall- and post- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, flat, tempered silk screened soda-lime glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution (FLAT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
071186 LED 25 W 120-277V 80 3000 Type II - 2730 1930 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071186

071188 LED 25 W 120-277V 80 3000 Type II - 2730 1930 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071188

071190 LED 25 W 120-277V 80 4000 Type II - 2940 2095 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071190

071192 LED 25 W 120-277V 80 4000 Type II - 2940 2095 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071192

071202 LED 25 W 120-277V 80 3000 Type II - 2730 1930 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071202

071203 LED 25 W 120-277V 80 4000 Type II - 2940 2095 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT B - 071203

Sources

LED 25 W
  • Wall- and post- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Micro-prismatic patterned, flat, tempered silk screened soda-lime glass diffuser (FLAT versions).
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution (FLAT).
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (ordered separately).
  • - Post accessory available for MIMIK 20 (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
MID POWER LEDS 120-277 V DIMMABLE 0-10V
071178 LED 13.5 W 120-277V 80 3000 Type II - 1365 960 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071178

071180 LED 13.5 W 120-277V 80 3000 Type II - 1365 960 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071180

071182 LED 13.5 W 120-277V 80 4000 Type II - 1470 1042 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071182

071184 LED 13.5 W 120-277V 80 4000 Type II - 1470 1042 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071184

071200 LED 13.5 W 120-277V 80 3000 Type II - 1365 960 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071200

071201 LED 13.5 W 120-277V 80 4000 Type II - 1470 1042 L80 B10 60000 Download

Documentation: MIMIK 20 FLAT M - 071201

Sources

LED 13.5 W
  • Wall- and post- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type II light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (ordered separately).
  • - Post accessory available for MIMIK 20 (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V - EMPK DIMMABLE 0-10V
071550 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071550

071552 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071552

071556 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071556

071558 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071558

071594 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071594

071596 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071596

HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071154 LED 26 W 120-277V 70 3000 Type II - 2790 2256 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071154

071156 LED 26 W 120-277V 70 3000 Type II - 2790 2256 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071156

071158 LED 26 W 120-277V 70 4000 Type II - 3120 2292 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071158

071160 LED 26 W 120-277V 70 4000 Type II - 3120 2292 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071160

071204 LED 26 W 120-277V 70 3000 Type II - 2790 2256 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071204

071205 LED 26 W 120-277V 70 4000 Type II - 3120 2292 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071205

071606 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071606

071608 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071608

071610 LED 15 W 120-277V 70 3000 Type II - 1653 1385 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071610

071612 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071612

071614 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071614

071622 LED 15 W 120-277V 70 4000 Type II - 1780 1408 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE II - 071622

Sources

LED 15 W
LED 26 W
  • Wall- and post- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (ordered separately).
  • - Post accessory available for MIMIK 20 (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V - EMPK DIMMABLE 0-10V
071570 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071570

071572 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071572

071576 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071576

071578 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071578

071598 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071598

071600 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071600

HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071162 LED 26 W 120-277V 70 3000 Type III - 2790 2273 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071162

071164 LED 26 W 120-277V 70 3000 Type III - 2790 2273 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071164

071166 LED 26 W 120-277V 70 4000 Type III - 3120 2309 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071166

071168 LED 26 W 120-277V 70 4000 Type III - 3120 2309 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071168

071206 LED 26 W 120-277V 70 3000 Type III - 2790 2273 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071206

071207 LED 26 W 120-277V 70 4000 Type III - 3120 2309 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071207

071624 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071624

071626 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071626

071627 LED 15 W 120-277V 70 3000 Type III - 1653 1396 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071627

071628 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071628

071629 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071629

071630 LED 15 W 120-277V 70 4000 Type III - 1780 1418 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE III - 071630

Sources

LED 15 W
LED 26 W
  • Wall- and post- mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - IESNA Type IV light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - Customizing facade faceplate cover available for MIMIK FLAT versions (ordered separately).
  • - Post accessory available for MIMIK 20 (ordered separately).
  • - Consult factory for dimming options, custom finishes and non-cataloged CCT (Kelvin) options.
  • - Optional clear plexiglas panel can be customized with logos for signage or wayfinding. Consult factory for more information.
  • - Product meets Buy American requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam
Lightsource
lumen
output
Luminaire
lumen
output
L B Lifetime Download
HIGH POWER LEDS 120-277 V - EMPK DIMMABLE 0-10V
071582 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071582

071584 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071584

071588 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071588

071590 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071590

071602 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071602

071604 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071604

HIGH POWER LEDS 120-277 V DIMMABLE 0-10V
071170 LED 26 W 120-277V 70 3000 Type IV - 2790 2149 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071170

071172 LED 26 W 120-277V 70 3000 Type IV - 2790 2149 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071172

071174 LED 26 W 120-277V 70 4000 Type IV - 3120 2183 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071174

071176 LED 26 W 120-277V 70 4000 Type IV - 3120 2183 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071176

071208 LED 26 W 120-277V 70 3000 Type IV - 2790 2149 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071208

071209 LED 26 W 120-277V 70 4000 Type IV - 3120 2183 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071209

071631 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071631

071632 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071632

071633 LED 15 W 120-277V 70 3000 Type IV - 1653 1319 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071633

071634 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071634

071635 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071635

071636 LED 15 W 120-277V 70 4000 Type IV - 1780 1340 L80 B10 60000 Download

Documentation: MIMIK 20 M TYPE IV - 071636

Sources

LED 15 W
LED 26 W
to top
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
