MIMIK 10 BOLLARD

IN
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Optional, integral, line-voltage, passive infrared motion sensor (PIR SENSOR versions).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - Steel ground base plate available as accessory for HU versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
MIMIK 10 BOLLARD 1000 HU

MIMIK 10 BOLLARD 1000 HU

Optic | Cycle/Pedestrian Type III
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate available as accessory for HU versions (ordered separately).
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071940 LED 11 W 120/277 V 70 3000 Type II - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 071940
071941 LED 11 W 120/277 V 70 3000 Type II - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 071941
071942 LED 11 W 120/277 V 70 4000 Type II - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 071942
071943 LED 11 W 120/277 V 70 4000 Type II - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 071943
Power LED 100-277 V 50/60 Hz
072010 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 072010
072012 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 072012
072014 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 072014
072016 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 HU - 072016

Sources

LED 11 W
LED 10 W
MIMIK 10 BOLLARD 1000 SENSOR

MIMIK 10 BOLLARD 1000 SENSOR

  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral, line-voltage, passive infrared motion sensor (PIR SENSOR versions).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071826 LED 11 W 120/277 V 70 3000 Type II - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 071826
071828 LED 11 W 120/277 V 70 3000 Type II - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 071828
071830 LED 11 W 120/277 V 70 4000 Type II - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 071830
071831 LED 11 W 120/277 V 70 4000 Type II - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 071831
Power LED 100-277 V 50/60 Hz
072002 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 072002
072004 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 072004
072006 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 072006
072008 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 1000 SENSOR - 072008

Sources

LED 11 W
LED 10 W
MIMIK 10 BOLLARD 300

MIMIK 10 BOLLARD 300

Optic | Cycle/Pedestrian Type III
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071796 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071796
071798 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071798
071800 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071800
071802 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071802
Power LED 100-277 V 50/60 Hz
071985 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071985
071986 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071986
071987 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071987
071988 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 300 - 071988

Sources

LED 11 W
LED 10 W
MIMIK 10 BOLLARD 600

MIMIK 10 BOLLARD 600

Optic | Asymmetric Intensive
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071788 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071788
071790 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071790
071792 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071792
071794 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071794
Power LED 100-277 V 50/60 Hz
071989 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071989
071990 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071990
071991 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071991
071992 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 - 071992

Sources

LED 11 W
LED 10 W
MIMIK 10 BOLLARD 600 SENSOR

MIMIK 10 BOLLARD 600 SENSOR

Optic | Cycle/Pedestrian Type III
  • Pathway bollard series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
  • - Copper-free (<1%) aluminum extruded post.
  • - Extra-clear, tempered, silk-screened, flat glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - ustom MCPCB utilized to maximize heat dissipation and promote long LED life.
  • - Type II light distribution.
  • - Type III light distribution.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral driver.
  • - Integral, line-voltage, passive infrared motion sensor (PIR SENSOR versions).
  • - Pre-wired factory sealed cable for external electrical connection included.
  • - Steel ground base plate included for bollards.
  • - The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • - Product meets Buy American Act (BAA) requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finishing Lampholder Wattage Voltage CRI Kelvin Optic Beam
angle		 Lightsource
lumen
output
[lm]		 Luminaire
lumen
output
[lm]		 L B Lifetime Downloads
Mid Power LEDS 120-277 V
071818 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071818
071820 LED 11 W 120/277 V 70 3000 - - 1006 744 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071820
071822 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071822
071824 LED 11 W 120/277 V 70 4000 - - 1075 915 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071824
Power LED 100-277 V 50/60 Hz
071997 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071997
071998 LED 10 W 120/277 V 70 3000 Type III - 1000 633 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071998
071999 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 071999
072000 LED 10 W 120/277 V 70 4000 Type III - 1076 671 L80 B10 60000 Download

Documentation: MIMIK 10 BOLLARD 600 SENSOR - 072000

Sources

LED 11 W
LED 10 W

Product Family

MIMIK 30 MIMIK 30
MIMIK 20 MIMIK 20
MIMIK 10 MIMIK 10
MIMIK 10 CEILING MIMIK 10 CEILING
MIMIK 50 MIMIK 50
MIMIK 20 CEILING MIMIK 20 CEILING
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
