MIMIK 50

IN
  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution.
  • - IESNA Type III light distribution.
  • - IESNA Type IV light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Optional, integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
MIMIK 50 B TYPE II

MIMIK 50 B TYPE II

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079871 LED 39 W + 39 W 80 3000 Type II - 13260 8977 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079871
079872 LED 39 W + 39 W 80 4000 Type II - 13840 9614 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079872
079883 LED 39 W + 39 W 80 3000 Type II - 13260 8977 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079883
079884 LED 39 W + 39 W 80 4000 Type II - 13840 9614 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079884
079919 LED 53 W + 53 W 80 3000 Type II - 17260 11741 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079919
079920 LED 53 W + 53 W 80 4000 Type II - 18000 12575 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079920
079931 LED 53 W + 53 W 80 3000 Type II - 17260 11741 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079931
079932 LED 53 W + 53 W 80 4000 Type II - 18000 12575 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II - 079932

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 B TYPE II EMPK

MIMIK 50 B TYPE II EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079877 LED 39 W + 39 W 80 3000 Type II - 13260 8977 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079877
079878 LED 39 W + 39 W 80 4000 Type II - 13840 9614 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079878
079889 LED 39 W + 39 W 80 3000 Type II - 13260 8977 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079889
079890 LED 39 W + 39 W 80 4000 Type II - 13840 9614 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079890
079925 LED 53 W + 53 W 80 3000 Type II - 17260 11741 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079925
079926 LED 53 W + 53 W 80 4000 Type II - 18000 12575 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079926
079937 LED 53 W + 53 W 80 3000 Type II - 17260 11741 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079937
079938 LED 53 W + 53 W 80 4000 Type II - 18000 12575 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE II EMPK - 079938

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 B TYPE III

MIMIK 50 B TYPE III

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type III light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079873 LED 39 W + 39 W 80 3000 Type III - 13260 8787 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079873
079874 LED 39 W + 39 W 80 4000 Type III - 13840 9413 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079874
079885 LED 39 W + 39 W 80 3000 Type III - 13260 8787 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079885
079886 LED 39 W + 39 W 80 4000 Type III - 13840 9413 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079886
079921 LED 53 W + 53 W 80 3000 Type III - 17260 11494 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079921
079922 LED 53 W + 53 W 80 4000 Type III - 18000 12313 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079922
079933 LED 53 W + 53 W 80 3000 Type III - 17260 11494 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079933
079934 LED 53 W + 53 W 80 4000 Type III - 18000 12313 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III - 079934

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 B TYPE III EMPK

MIMIK 50 B TYPE III EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type III light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079879 LED 39 W + 39 W 80 3000 Type III - 13260 8787 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079879
079880 LED 39 W + 39 W 80 4000 Type III - 13840 9413 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079880
079891 LED 39 W + 39 W 80 3000 Type III - 13260 8787 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079891
079892 LED 39 W + 39 W 80 4000 Type III - 13840 9413 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079892
079927 LED 53 W + 53 W 80 3000 Type III - 17260 11494 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079927
079928 LED 53 W + 53 W 80 4000 Type III - 18000 12313 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079928
079939 LED 53 W + 53 W 80 3000 Type III - 17260 11494 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079939
079940 LED 53 W + 53 W 80 4000 Type III - 18000 12313 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE III EMPK - 079940

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 B TYPE IV

MIMIK 50 B TYPE IV

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type IV light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079875 LED 39 W + 39 W 80 3000 Type IV - 13260 8388 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079875
079876 LED 39 W + 39 W 80 4000 Type IV - 13840 8982 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079876
079887 LED 39 W + 39 W 80 3000 Type IV - 13260 8388 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079887
079888 LED 39 W + 39 W 80 4000 Type IV - 13840 8982 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079888
079923 LED 53 W + 53 W 80 3000 Type IV - 17260 10970 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079923
079924 LED 53 W + 53 W 80 4000 Type IV - 18000 11749 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079924
079935 LED 53 W + 53 W 80 3000 Type IV - 17260 10970 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079935
079936 LED 53 W + 53 W 80 4000 Type IV - 18000 11749 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV - 079936

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 B TYPE IV EMPK

MIMIK 50 B TYPE IV EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type IV light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079881 LED 39 W + 39 W 80 3000 Type IV - 13260 8388 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079881
079882 LED 39 W + 39 W 80 4000 Type IV - 13840 8982 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079882
079893 LED 39 W + 39 W 80 3000 Type IV - 13260 8388 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079893
079894 LED 39 W + 39 W 80 4000 Type IV - 13840 8982 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079894
079929 LED 53 W + 53 W 80 3000 Type IV - 17260 10970 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079929
079930 LED 53 W + 53 W 80 4000 Type IV - 18000 11749 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079930
079941 LED 53 W + 53 W 80 3000 Type IV - 17260 10970 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079941
079942 LED 53 W + 53 W 80 4000 Type IV - 18000 11749 L80 B10 71000 Download

Documentation: MIMIK 50 B TYPE IV EMPK - 079942

Sources

LED 39 W + 39 W
LED 53 W + 53 W
MIMIK 50 M TYPE II

MIMIK 50 M TYPE II

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079847 LED 39 W 80 3000 Type II - 6630 4517 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079847
079848 LED 39 W 80 4000 Type II - 6920 4837 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079848
079859 LED 39 W 80 3000 Type II - 6630 4517 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079859
079860 LED 39 W 80 4000 Type II - 6920 4837 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079860
079895 LED 53 W 80 3000 Type II - 8630 5908 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079895
079896 LED 53 W 80 4000 Type II - 9000 6328 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079896
079907 LED 53 W 80 3000 Type II - 8630 5908 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079907
079908 LED 53 W 80 4000 Type II - 9000 6328 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II - 079908

Sources

LED 39 W
LED 53 W
MIMIK 50 M TYPE II EMPK

MIMIK 50 M TYPE II EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type II light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079853 LED 39 W 80 3000 Type II - 6630 4517 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079853
079854 LED 39 W 80 4000 Type II - 6920 4837 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079854
079865 LED 39 W 80 3000 Type II - 6630 4517 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079865
079866 LED 39 W 80 4000 Type II - 6920 4837 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079866
079901 LED 53 W 80 3000 Type II - 8630 5908 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079901
079902 LED 53 W 80 4000 Type II - 9000 6328 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079902
079913 LED 53 W 80 3000 Type II - 8630 5908 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079913
079914 LED 53 W 80 4000 Type II - 9000 6328 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE II EMPK - 079914

Sources

LED 39 W
LED 53 W
MIMIK 50 M TYPE III

MIMIK 50 M TYPE III

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type III light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079849 LED 39 W 80 3000 Type III - 6630 4422 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079849
079850 LED 39 W 80 4000 Type III - 6920 4736 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079850
079861 LED 39 W 80 3000 Type III - 6630 4422 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079861
079862 LED 39 W 80 4000 Type III - 6920 4736 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079862
079897 LED 53 W 80 3000 Type III - 8630 5784 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079897
079898 LED 53 W 80 4000 Type III - 9000 6196 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079898
079909 LED 53 W 80 3000 Type III - 8630 5784 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079909
079910 LED 53 W 80 4000 Type III - 9000 6196 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III - 079910

Sources

LED 39 W
LED 53 W
MIMIK 50 M TYPE III EMPK

MIMIK 50 M TYPE III EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type III light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079855 LED 39 W 80 3000 Type III - 6630 4422 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079855
079856 LED 39 W 80 4000 Type III - 6920 4736 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079856
079867 LED 39 W 80 3000 Type III - 6630 4422 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079867
079868 LED 39 W 80 4000 Type III - 6920 4736 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079868
079903 LED 53 W 80 3000 Type III - 8630 5784 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079903
079904 LED 53 W 80 4000 Type III - 9000 6196 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079904
079915 LED 53 W 80 3000 Type III - 8630 5784 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079915
079916 LED 53 W 80 4000 Type III - 9000 6196 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE III EMPK - 079916

Sources

LED 39 W
LED 53 W
MIMIK 50 M TYPE IV

MIMIK 50 M TYPE IV

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type IV light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - Dimmable 0-10 V
079851 LED 39 W 80 3000 Type IV - 6630 4219 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079851
079852 LED 39 W 80 4000 Type IV - 6920 4519 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079852
079863 LED 39 W 80 3000 Type IV - 6630 4219 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079863
079864 LED 39 W 80 4000 Type IV - 6920 4519 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079864
079899 LED 53 W 80 3000 Type IV - 8630 5520 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079899
079900 LED 53 W 80 4000 Type IV - 9000 5912 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079900
079911 LED 53 W 80 3000 Type IV - 8630 5520 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079911
079912 LED 53 W 80 4000 Type IV - 9000 5912 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV - 079912

Sources

LED 39 W
LED 53 W
MIMIK 50 M TYPE IV EMPK

MIMIK 50 M TYPE IV EMPK

  • Wall mount series. Fixtures consist of:
  • - Multi-step powder-coat painting process, optimized against UV rays and corrosion.
  • - Copper-free precision die-cast aluminum housing and mounting plate.
  • - Extra-clear, flat, tempered silk-screened soda-lime glass diffuser.
  • - Custom molded, anti-aging gasket(s).
  • - Stainless steel external hardware.
  • - Custom MCPCB utilized to maximize heat dissipation and promote a long LED life.
  • - High-transmittance transparent optics.
  • - Single (M) or dual (B) light emission.
  • - IESNA Type IV light distribution.
  • - Standard dual-circuit wiring and dimming for dual (B) light emission models.
  • - Input voltage: 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver.
  • - Integral, emergency battery-pack designed for a minimum operation of 90 minutes (EMPK versions).
  • - BUTTON and SWIVEL photoelectric switch options available (ordered separately).
  • - Consult factory for dimming options, custom finishes (please specify RAL color), and non-cataloged CCT (Kelvin) options.
  • - Product meets Buy American Act requirements within ARRA.
  • - 5-year warranty.
Product codes
Part number Finish Lampholder Wattage Voltage CRI Kelvin Optic Optic
Beam		 Lightsource
lumen
output		 Luminaire
lumen
output		 L B Lifetime Download
Mid Power LEDS 120-277 V - EMPK - Dimmable 0-10 V
079857 LED 39 W 80 3000 Type IV - 6630 4219 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079857
079858 LED 39 W 80 4000 Type IV - 6920 4519 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079858
079869 LED 39 W 80 3000 Type IV - 6630 4219 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079869
079870 LED 39 W 80 4000 Type IV - 6920 4519 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079870
079905 LED 53 W 80 3000 Type IV - 8630 5520 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079905
079906 LED 53 W 80 4000 Type IV - 9000 5912 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079906
079917 LED 53 W 80 3000 Type IV - 8630 5520 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079917
079918 LED 53 W 80 4000 Type IV - 9000 5912 L80 B10 71000 Download

Documentation: MIMIK 50 M TYPE IV EMPK - 079918

Sources

LED 39 W
LED 53 W

Product Family

MIMIK 30 MIMIK 30
MIMIK 20 MIMIK 20
MIMIK 10 BOLLARD MIMIK 10 BOLLARD
MIMIK 10 MIMIK 10
MIMIK 10 CEILING MIMIK 10 CEILING
to top
Request information
Products search
You can search for products in our catalog by entering here the name or the code of the product or accessory.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
