The more the better
The GUELL floodlighting series offers a high-quality fixture fabrication at a cost-effective price providing effectively delivered lumens. These high output fixtures do more than provide exceptional light. They look great with the lights off too. With a contemporary die-cast body design and high-performance reflectors, you can choose from an assortment of mounting options and use these beautiful fixtures everywhere, from your parking lots and sports areas to signage and egress lighting. The GUELL offers a higher quality of light using fewer watts and better optics. With various symmetric and asymmetric beam options as well as integral photocontrol and motion sensor options, the GUELL is the perfect fit for your high lumen fixture demands. The main focus of this product family is to offer a massive reduction in power consumption, resulting in an improved total cost of investment thanks to a long service life of the electrical components, sourced from reliable and well-established sources, and to an innovative passive cooling thermal management system.Secure mounting options such as swivel arms for adjustable wall or roof mounting are perfect for area and sign lighting; slip fitters for pole top or bullhorn mounting ideal for landscape and signs round out the product family offering to make this suitable for almost every application.
Long-lasting energy-efficient floodlight series. Fixtures consist of:
  • Copper-free (<1%) precision die-cast aluminum housing, and adjustable steel mounting bracket.
  • High-efficiency COB, combined with an optimized passive cooling system, provides a long LED life.
  • Internal specular reflector coated with 5-layers of PVD 99.98% pure aluminum providing >95% reflection.
  • Extra-clear, tempered, silk-screened, flat glass diffuser.
  • Custom molded, anti-aging gasket(s).
  • Stainless steel external hardware.
  • Available in four standard size of H9" x L8.2" x D2.3" (GUELL ZERO), H12.6" x L9.2" x D3.3" (GUELL 1), H12.6" x L14.5" x D3.3" (GUELL 2), H19.7" x L22.2" x D3.9" (GUELL 3) and H22.4" x L22.2" x D3.9" (GUELL 4).
  • Pre-wired factory sealed cable for external electrical connection included.
  • Standard quick release latch(es) allow for tool-free access.
  • Standard swivel arm (GUELL ZERO / 1 SA versions) and slip-fitter (GUELL 2 / 3 SF versions) for simplified installation.
  • Louver, frosted glass, protective grid, wall support 19.69" / 39.37", single or double pole top support, and matching junction box plate accessories available (ordered separately).
  • NEMA 6H x 5V, 7H x 5V, 7H x 6V, 7H x 7V and 6H x 5V light distributions.
  • Input voltage: 120-277 V (50 / 60 Hz), integral driver (GUELL 4); 120-277 V (50 / 60 Hz), integral 0-10 V dimming driver (GUELL 1 / 2 / 3) and 120-277 V (50 / 60 Hz), integral 1-10 V dimming driver (GUELL ZERO).
  • The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
  • UL Wet location listed. IP66 rated.
  • Product meets Buy American Act (BAA) requirements within ARRA.
  • Consult factory for which version qualifies for the PRONTO-SHIP program. All Rough-Ins are available to ship within 48-72 hrs. Orders must be marked "PRONTO."
  • Photometric data measured according to UNI EN 13032-1/4 and IES LM-79-08
  • The light distribution complies with the IESNA Full Cut-Off Classification and is eligible for all “Dark Sky” applications when aimed down.
  • Actual performance may differ as a result of the end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications are subject to change without notice.
  • DesignLights Consortium® (DLC) qualified product. Not all versions of this product may be DLC qualified. Please check the DLC Qualified Products List at to confirm which versions are qualified.
  • 5-year limited warranty. Complete warranty terms located at
