INSERT+1

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type III light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Stainless steel recessed rough-in kit to be ordered separately.
- Optional INSERT+ 1 marine-grade, polished, brass faceplate suitable for coastal applications available (ordered separately).
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

INSERT+ 1 [8.82”]

Optic | Asymmetric Medium

Recessed wall steplight series. Fixtures consist of:
- Multi-step powder-coat painting process, optimized against UV rays and corrosion.
- Copper-free (<1%) precision die-cast aluminum housing and ring/faceplate.
- Frosted, tempered, silk-screened, flat glass diffuser.
- Custom molded, anti-aging gasket(s).
- Stainless steel external hardware.
- Custom MCPCB utilized to maximize heat dissipation and promote long LED life.
- Type III light distribution.
- Input voltage: 120-277 V (50 / 60 Hz), integral driver.
- Pre-wired factory sealed cable for external electrical connection included.
- Stainless steel recessed rough-in kit to be ordered separately.
- Optional INSERT+ 1 marine-grade, polished, brass faceplate suitable for coastal applications available (ordered separately).
- The luminaire may be configured with numerous options and multiple standard finishes. Not all options are available in all configurations. Consult factory for more information about specification sheet details to build your light.
- Product meets Buy American Act (BAA) requirements within ARRA.
- 5-year warranty.

Product codes

Part number	Lampholder	Wattage	Voltage	CRI	Kelvin	Optic	Beam angle	Lightsource lumen output [lm]	Luminaire lumen output [lm]	L	B	Lifetime	Downloads
Mid Power LEDS 120-277 V
071417	LED	7 W	120/277 V	80	3000	-	-	825	250	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071417
071419	LED	7 W	120/277 V	80	3000	-	-	825	250	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071419
071421	LED	7 W	120/277 V	80	3000	-	-	825	250	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071421
071422	LED	7 W	120/277 V	80	4000	-	-	850	275	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071422
071423	LED	7 W	120/277 V	80	4000	-	-	850	275	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071423
071424	LED	7 W	120/277 V	80	4000	-	-	850	275	L80	B10	60000	Documentation: INSERT+ 1 [8.82”] - 071424
