SHIELD+
Installs are a cinch
SHIELD+ offers a versatile architectural style ideal for walls, facades, canopies and perimeter lighting. The injection-moulded metallised reflectors offer precise light, an anti-glare design and precision optical control.
SHIELD+ 1, thanks to the proprietary driver, can be set up to three different levels (MULTIPOWER). This innovative system allows field power to adjust according to specific needs. Moreover, the predispositions for side-cable entry in three different positions, the standard loop-in/loop-out from the back-side and the EXTREME options, make the series installable in any context.
Range
Features & benefits
  • Designed to last
  • Designed for use in extreme environmental conditions
  • Excellent heating dissipation
  • Compliance with anti-light pollution laws
  • Constant luminous flux over time
  • MULTIPOWER standard: selectable power sizes inside the luminaire
  • Equipped with emergency lights
  • DALI versions available
  • Surge protected
  • Openable and maintainable luminaire
  • High quality BIM objects available
  • Made in Italy
Wall-mounted LED luminaire, comprising:
Construction
  • Die-cast aluminium housing, polyester powder coat finish ISO 9227/12944 - ISO 9223 (C5)
  • High-efficiency metallized technopolymer reflector with protective surface treatment
  • Anti-ageing custom moulded silicone sealing gasket(s)
  • Extra clear, toughened, flat glass diffuser
Electrical
  • Static ON/OFF or dimmable DALI options available
  • EM/3P version is designed for multipurpose 3 hours sustained emergency lighting
  • Li-Fe Po4 3,2 V 3.0 Ah batteries, 24 hours recharge time
Installation
  • Field settable integral tri-level lumen/wattage packages proprietary DIP switch driver
  • Through-wiring designed
  • EXTREME options are suitable for extreme operating temp. conditions , -40°C
Variants
  • Twilight models (C versions) complete with dusk sensor available. Consult factory
Listings
  • CE / UKCA
  • RCM
Warranty
  • 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
;
